Product Details of [ 170017-73-9 ]

CAS No. :170017-73-9
Formula : C15H21N3O4
M.W : 307.34
SMILES Code : O=C(N1CCN(C2=CC=CC=C2[N+]([O-])=O)CC1)OC(C)(C)C
MDL No. :MFCD08275017
InChI Key :GTGIZVUOLBRDAO-UHFFFAOYSA-N
Pubchem ID :21935210

Safety of [ 170017-73-9 ]

GHS Pictogram:
Signal Word:Warning
Hazard Statements:H315-H319
Precautionary Statements:P264-P280-P302+P352-P305+P351+P338-P332+P313-P337+P313-P362

Application In Synthesis of [ 170017-73-9 ]

* All experimental methods are cited from the reference, please refer to the original source for details. We do not guarantee the accuracy of the content in the reference.

  • Downstream synthetic route of [ 170017-73-9 ]

[ 170017-73-9 ] Synthesis Path-Downstream   1~1

  • 1
  • [ 170017-73-9 ]
  • [ 170017-74-0 ]
YieldReaction ConditionsOperation in experiment
94.8% With 5%-palladium/activated carbon; hydrogen; In ethanol; for 2.5h; (Production Example 1-2) Synthesis of Compound 13 (t-butyl-4- (2-aminophenyl) piperazine-1-carboxylate) In the reaction flask was added compound 12 (299g, 974mml) and ethanol was added 5% palladium on carbon (30g). While blowing hydrogen into the reaction mixture obtained, thereby being reacted 2.5 hours.After the reaction mixture was filtered, concentrated under reduced pressure to give compound 13 (256g, yield 94.8%)
94.8% With 5%-palladium/activated carbon; hydrogen; In ethanol; for 2.5h; Compound 12 (299 g, 974 mmol) and ethanol were charged in a reaction flask,5% palladium on carbon (30 g) was added. Hydrogen gas was not blown into the obtained reaction mixtureLet it react for 2.5 hours.The reaction mixture was filtered and concentrated under reduced pressure to obtain Compound 13 (256 g, yield 94.8%)Obtained.
89% With iron; ammonium chloride; In ethanol; water; at 90℃; for 2h; To a solution of tert-butyl-4-(2-nitrophenyl)piperazine-l-carboxylate (1.0 g, 3.25 mmol) in EtOH (30 mL) and H20 (15 mL) at rt was added NH4Cl (870 mg, 16.25 mmol) and Fe (1.09 g, 19.5 mmol). The reaction mixture was stirred at 90C for 2 hrs, then cooled to rt and extracted with EtOAc (50 mL x 3). The combined organic layers were washed with brine, dried over Na2SO4, filtered, concentrated, and purified by chromatography (silica, EtOAc/PE = 1/5) to afford ter/-butyl-4-(2-aminophenyl)piperazine-l-carboxylate (800 mg, 2.88 mmol, 89%) as an oil. ESI-MS (EI+, m/z): 278.4 [M+H]+.
89% With ethanol; iron; ammonium chloride; In water; at 90℃; for 2h; Step 3: tert-butyl 4-(2-aminophenyl)piperazine-1-carboxylate To a solution of tert-butyl-4-(2-nitrophenyl)piperazine-1-carboxylate (1.0 g, 3.25 mmol) in EtOH (30 mL) and H2O (15 mL) at rt was added NH4Cl (870 mg, 16.25 mmol) and Fe (1.09 g, 19.5 mmol). The reaction mixture was stirred at 90 C. for 2 hrs, then cooled to rt and extracted with EtOAc (50 mL*3). The combined organic layers were washed with brine, dried over Na2SO4, filtered, concentrated, and purified by chromatography (silica, EtOAc/PE=1/5) to afford tert-butyl-4-(2-aminophenyl)piperazine-1-carboxylate (800 mg, 2.88 mmol, 89%) as an oil. ESI-MS (EI+, m/z): 278.4 [M+H]+.
74% With 5%-palladium/activated carbon; hydrogen; In methanol; under 7500.75 Torr; for 14h; To a solution of lllb (1 .00 g, 3.25 mmol) in MeOH (10 mL) Pd/C (5%, 50 mg) was carefully added. Obtained mixture was hydrogenated under 10 bar H2 for 14 h. Pd/C was then filtered off and solvent evaporated to afford an oil, which crystalized upon standing. The product was recrystallized from MeCy (10 mL), precipitate was filtered off, washed with MeCy (2 x 5 mL) and dried to afford the title compound IVb as light violet powder. (0.67 g, 74% yield): H NMR (CDCI3, 500 MHz) δ 1 .50 (s, 9H), 2.87 (m, 4H), 3.57 (br s, 2H), 3.99 (m, 4H), 6.75 (m, 2H), 6.94-6.99 (m, 2H); MS (ESI) mz. 278 [MH]+.
74% With 5%-palladium/activated carbon; hydrogen; In methanol; under 7500.75 Torr; for 14h; To a solution of IIIb (1.00 g, 3.25 mmol) in MeOH (10 mL) Pd/C (5%, 50 mg) was carefully added. Obtained mixture was hydrogenated under 10 bar H2 for 14 h. Pd/C was then filtered off and solvent evaporated to afford an oil, which crystalized upon standing. The product was recrystallized from MeCy (10 mL), precipitate was filtered off, washed with MeCy (2 x 5 mL) and dried to afford the title compound IVb as light violet powder. (0.67 g, 74% yield): 1H NMR (CDCl3, 500 MHz) δ 1.50 (s, 9H), 2.87 (m, 4H), 3.57 (br s, 2H), 3.99 (m, 4H), 6.75 (m, 2H), 6.94-6.99 (m, 2H); MS (ESI) m/z: 278 [MH]+.
palladium; In ethanol; PREPARATION 13 1-[1,1-Dimethylethoxycarbonyl]-4-(2-aminophenyl)piperazine 1-[1,1-Dimethylethoxycarbonyl]-4-(2-nitrophenyl)piperazine (PREPARATION 12, 7.61 g) is dissolved in ethanol (150 ml). Palladium on carbon (10%, 0.75 g) is added and the reaction is hydrogenated at 45 psi for 6 hr. The mixture is filtered thru celite and concentrated under reduced pressure to give the title compound.
25.3 g With 5% Pd/C; hydrogen; In ethanol; at 35 - 40℃; under 1551.49 - 2068.65 Torr; for 10h; Ortho-fluoronitrobenzene (14.1 g, 0.1 mol), 4-tert-butoxycarbonyl-1-piperazine (18.6 g, 0.1 mol), and potassium carbonate (13.8 g, 0.4 mol) were added to acetonitrile (140 ml), stirred and heated to reflux. After reacting for 16 h, the reaction system was cooled to room temperature, filtered under reduced pressure to remove inorganic salts. Then, the filter cake was washed with acetonitrile (40 ml), and the filtrate was merged and concentrated to a slurry system under reduced pressure. Ethanol (140 ml) was added and concentrated to obtain a slurry system, after that ethanol (140 ml) was added, and stirred until clarification. Then a wet palladium/carbon (7% palladium) (1.12 g) was added. The system was purged with nitrogen gas (40 psi) for three times and then hydrogen gas (40 psi) for three times. Hydrogenation was carried out, under the pressure of 30 to 40 psi and at the temperature of 35 to 40 C. for 10 h, then cooled to room temperature, and filtered to remove palladium/carbon. The filter cake was washed with ethanol (30 ml), and the filtrate was merged and concentrated to dry under reduced pressure. A pale yellow solid of 25.3 g was obtained, and the yield was 91.2%; MS+=278.2.



Historical Records

Technical Information

Categories

Related Functional Groups of
[ 170017-73-9 ]

Aryls

Chemical Structure| 23470-45-3

A867163 [23470-45-3]

Ethyl 4-(3-amino-4-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.93

Chemical Structure| 182618-86-6

A128710 [182618-86-6]

1-Boc-4-(4-Nitrophenyl)piperazine

Similarity: 0.93

Chemical Structure| 206879-94-9

A539340 [206879-94-9]

tert-Butyl 4-(3-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.92

Chemical Structure| 834881-63-9

A514347 [834881-63-9]

tert-Butyl (2-((2-nitrophenyl)amino)ethyl)carbamate

Similarity: 0.91

Chemical Structure| 874814-94-5

A664128 [874814-94-5]

tert-Butyl 4-(4-fluoro-2-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.91

Amides

Chemical Structure| 23470-45-3

A867163 [23470-45-3]

Ethyl 4-(3-amino-4-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.93

Chemical Structure| 182618-86-6

A128710 [182618-86-6]

1-Boc-4-(4-Nitrophenyl)piperazine

Similarity: 0.93

Chemical Structure| 206879-94-9

A539340 [206879-94-9]

tert-Butyl 4-(3-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.92

Chemical Structure| 834881-63-9

A514347 [834881-63-9]

tert-Butyl (2-((2-nitrophenyl)amino)ethyl)carbamate

Similarity: 0.91

Chemical Structure| 874814-94-5

A664128 [874814-94-5]

tert-Butyl 4-(4-fluoro-2-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.91

Nitroes

Chemical Structure| 23470-45-3

A867163 [23470-45-3]

Ethyl 4-(3-amino-4-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.93

Chemical Structure| 182618-86-6

A128710 [182618-86-6]

1-Boc-4-(4-Nitrophenyl)piperazine

Similarity: 0.93

Chemical Structure| 206879-94-9

A539340 [206879-94-9]

tert-Butyl 4-(3-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.92

Chemical Structure| 834881-63-9

A514347 [834881-63-9]

tert-Butyl (2-((2-nitrophenyl)amino)ethyl)carbamate

Similarity: 0.91

Chemical Structure| 874814-94-5

A664128 [874814-94-5]

tert-Butyl 4-(4-fluoro-2-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.91

Related Parent Nucleus of
[ 170017-73-9 ]

Piperazines

Chemical Structure| 23470-45-3

A867163 [23470-45-3]

Ethyl 4-(3-amino-4-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.93

Chemical Structure| 182618-86-6

A128710 [182618-86-6]

1-Boc-4-(4-Nitrophenyl)piperazine

Similarity: 0.93

Chemical Structure| 206879-94-9

A539340 [206879-94-9]

tert-Butyl 4-(3-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.92

Chemical Structure| 874814-94-5

A664128 [874814-94-5]

tert-Butyl 4-(4-fluoro-2-nitrophenyl)piperazine-1-carboxylate

Similarity: 0.91

Chemical Structure| 1290181-36-0

A699542 [1290181-36-0]

tert-Butyl 4-(4-formyl-2-nitrophenyl)piperazine-1-carboxylate
