Purity | Size | Price | VIP Price | USA Stock *0-1 Day | Global Stock *5-7 Days | Quantity | |||||
{[ item.p_purity ]} | {[ item.pr_size ]} |
{[ getRatePrice(item.pr_usd, 1,1) ]} {[ getRatePrice(item.pr_usd,item.pr_rate,item.mem_rate) ]} |
{[ getRatePrice(item.pr_usd, 1,1) ]} | Inquiry {[ getRatePrice(item.pr_usd,item.pr_rate,item.mem_rate) ]} {[ getRatePrice(item.pr_usd,1,item.mem_rate) ]} | {[ item.pr_usastock ]} | Inquiry - | {[ item.pr_chinastock ]} | Inquiry - |
* Storage: {[proInfo.prStorage]}
CAS No. : | 2234-45-9 | MDL No. : | MFCD01568856 |
Formula : | C17H13BrO | Boiling Point : | - |
Linear Structure Formula : | - | InChI Key : | QVVBDTXZESAKDU-UHFFFAOYSA-N |
M.W : | 313.19 | Pubchem ID : | 640595 |
Synonyms : |
|
Num. heavy atoms : | 19 |
Num. arom. heavy atoms : | 16 |
Fraction Csp3 : | 0.06 |
Num. rotatable bonds : | 3 |
Num. H-bond acceptors : | 1.0 |
Num. H-bond donors : | 0.0 |
Molar Refractivity : | 82.63 |
TPSA : | 9.23 Ų |
GI absorption : | High |
BBB permeant : | Yes |
P-gp substrate : | No |
CYP1A2 inhibitor : | Yes |
CYP2C19 inhibitor : | Yes |
CYP2C9 inhibitor : | Yes |
CYP2D6 inhibitor : | No |
CYP3A4 inhibitor : | No |
Log Kp (skin permeation) : | -4.43 cm/s |
Log Po/w (iLOGP) : | 3.33 |
Log Po/w (XLOGP3) : | 5.33 |
Log Po/w (WLOGP) : | 5.03 |
Log Po/w (MLOGP) : | 4.78 |
Log Po/w (SILICOS-IT) : | 5.12 |
Consensus Log Po/w : | 4.72 |
Lipinski : | 1.0 |
Ghose : | None |
Veber : | 0.0 |
Egan : | 0.0 |
Muegge : | 2.0 |
Bioavailability Score : | 0.55 |
Log S (ESOL) : | -5.56 |
Solubility : | 0.000853 mg/ml ; 0.00000272 mol/l |
Class : | Moderately soluble |
Log S (Ali) : | -5.28 |
Solubility : | 0.00166 mg/ml ; 0.0000053 mol/l |
Class : | Moderately soluble |
Log S (SILICOS-IT) : | -7.57 |
Solubility : | 0.00000843 mg/ml ; 0.0000000269 mol/l |
Class : | Poorly soluble |
PAINS : | 0.0 alert |
Brenk : | 0.0 alert |
Leadlikeness : | 1.0 |
Synthetic accessibility : | 1.79 |
Signal Word: | Warning | Class: | N/A |
Precautionary Statements: | P264-P280-P302+P352-P305+P351+P338-P332+P313-P337+P313-P362 | UN#: | N/A |
Hazard Statements: | H315-H319 | Packing Group: | N/A |
GHS Pictogram: |
* All experimental methods are cited from the reference, please refer to the original source for details. We do not guarantee the accuracy of the content in the reference.
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
86% | With potassium carbonate In N,N-dimethyl-formamide at 100℃; for 3.5h; | |
78% | With potassium carbonate In N,N-dimethyl-formamide at 80℃; | 1 2-Benzyloxy-6-bromo-naphthalene (1a) 6-Bromonaphtol (25.2 g, 113 mmol) and benzyl chloride (39.0 mL, 339 mmol) were dissolved in N,N-dimethylformamide (125 mL). Potassium carbonate (46.9 g, 399 mmol) and sodium iodide (1.69 g, 11.3 mmol) were added and the mixture was stirred at 80° C. overnight. The reaction mixture was concentrated in vacuo. Water and ethyl acetate were added and the phases were separated. The aqueous phase was extracted with ethyl acetate. The combined organic phases were washed with brine, dried over sodium sulphate filtrated and concentrated in vacuo. Recrystallisation from ethanol gave 2-benzyloxy-6-bromo-naphthalene (27.8 g, 78%) as a white crystalline compound. |
56% | With sodium In ethanol for 6h; Heating; |
With potassium hydroxide In methanol | ||
In ethanol | 41.i (i) (i) Synthesis of 2-(benzyloxy)-6-bromonaphthalene 2-(benzyloxy)-6-bromonaphthalene was obtained in the same manner as in the step (i) of the Example 27, except for using 6-bromo-2-naphthol and benzyl chloride instead of 4-(benzyloxy)phenol and n-propyl bromide, respectively, and using ethanol as the recrystallization solvent. | |
With sodium hydroxide In water; dimethyl sulfoxide | 25.1 Example 25 (1) To 500 ml of DMSO containing 50 g of 6-bromo-2-naphthol dissolved therein, were added 30 ml of aqueous solution containing 10 g of sodium hydroxide, and stirred to obtain a homogeneous solution. Then 30 g of benzyl chloride were added thereto and stirred for 3 days at the room temperature. The resulting solution was thrown into 2 l of iced water. The resultant precipitates were filterred and recrystallized with ethanol to obtain 67 g of 6-bromo-2-benzyloxynaphthalene. | |
With sodium hydroxide In dimethyl sulfoxide | 9.1 Example 9 (1) Into 500 ml of DMSO containing 50 g of 6-bromo-2-naphthol dissolved therein, were added 20 ml of an aqueous solution of 9.8 g of sodium hydroxide, and stirred into a homogeneous solution. Then, 32 g of benzyl chloride were added devided into three parts, and stirred for 3 days at room temperature. Thereafter, the reaction product was thrown into iced water, and the resulting precipitates were filtered, dried and then recrystallized with ethanol to obtain 65.0 g of 2-benzyloxy-6-bromonaphthalene. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
61% | In N,N-dimethyl-formamide at 150℃; for 24h; | |
With pyridine; copper(II) sulfate In N,N-dimethyl-formamide |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
95% | Stage #1: 6-bromo-naphthalen-2-ol With sodium hydride In N,N-dimethyl-formamide; mineral oil at 0℃; Stage #2: benzyl bromide In N,N-dimethyl-formamide; mineral oil | 1.6 In a dry single neck round bottom flask, sodium hydride (460 mg, 20 mmol, 2 equiv.) was added to 6-bromo- 2-naphthol (2.2 g, 10 mmol, 1 equiv.) in anhydrous ^.A'-dimethylformamide (15 mL) at 0 °C. Approximately 15-20 minutes later, benzyl bromide (1.2 mL, 10 mmol, 1 equiv.) was added drop- wise and the stirring was continued until the starting material was completely consumed. It takes generally 3-4 h for the reaction to go to completion. Saturated aqueous NaHC03 was added to the reaction mixture, and the solution was extracted with EtOAc. The combined organic layers were washed with water and saturated aqueous NaCl solution, dried over anhydrous Na2S04, filtered, and concentrated. The residue was purified on silca gel to provide the desired product with 95% of yield as white solid. |
90% | Stage #1: 6-bromo-naphthalen-2-ol With sodium hydride In N,N-dimethyl-formamide at 0℃; for 0.25h; Stage #2: benzyl bromide In N,N-dimethyl-formamide at 0 - 20℃; for 18h; | |
79% | With potassium carbonate In butanone for 86.4h; Heating; |
75% | With sodium hydride In N,N-dimethyl-formamide at 70℃; for 22h; | |
71% | Stage #1: 6-bromo-naphthalen-2-ol With sodium hydride In N,N-dimethyl-formamide; mineral oil at 0℃; for 0.25h; Stage #2: benzyl bromide In N,N-dimethyl-formamide; mineral oil at 20℃; for 18h; | Intermediate 26: 2-(benzyloxy)-6-bromonaphthalene To a stirred and cooled (0 °C) solution of 6-bromo-2-naphthol (5.00 g, 22.4 mmol) in DMF (50 mE) was added sodium dydride (60%, 1.16 g, 29.1 mmol) in portions. After addition, stiningwas continued for 15 mm, and then benzyl bromide (3.5 g, 20.2 mmol) was added. The reaction mixture was stirred at room temperature for 18 h. The mixture was quenched by addition of saturated aqueous NH4CJ (100 mL) and then extracted with ethyl acetate (3 x 150 mL). The combined organic Layers were washed with water (3 x 100 mL), brine (100 mL), dried (Na2SO4) and concentrated under reduced pressure. The residue was purified by silica-gelchromatography (petroleum ether: ethyl acetate = 10: 1) to give the title compound (5.0 g, 71% yield) as a white solid. |
With sodium ethanolate; potassium iodide | ||
With potassium carbonate | ||
With sodium hydride In N,N-dimethyl-formamide at 0 - 20℃; for 1h; | ||
With NaH; ammonium chloride In i-PrOAc; N,N-dimethyl-formamide | 10.1 Step 1 Step 1 [(6-bromo-2-naphthyl)oxy](phenyl)methane To a mixture of 6-bromo-2-naphthol (1.99 g, 8.9 mmol) and benzyl bromide (1.2 ml, 1.1 equiv.) in DMF (18 ml) at 0° C. was added a suspension of NaH 80% in oil (324 mg, 1.2 equiv.) and the mixture was stirred at 0° C. for an hour and at r.t. for another hour. After addition of half saturated NH4Cl, the product was extracted in i-PrOAc, washed with 1N HCl, dried over Na2SO4 and concentrated to yield 2.84 g of an oil. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
With palladium diacetate; tetrabutyl-ammonium chloride; potassium acetate In N,N-dimethyl-formamide at 150℃; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
11% | Stage #1: 6-benzyloxy-2-bromonaphthalene With n-butyllithium In tetrahydrofuran; hexane at -77℃; for 0.75h; Stage #2: (-)-dimethy-2,3-O-isopropylidene-L-tartrate In tetrahydrofuran; hexane at -77 - 20℃; for 38h; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
76% | With tetrakis(triphenylphosphine) palladium(0); sodium carbonate at 80℃; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Stage #1: 6-benzyloxy-2-bromonaphthalene With n-butyllithium In tetrahydrofuran at -78℃; Stage #2: Triisopropyl borate In tetrahydrofuran at 20℃; for 16h; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 2 steps 1.1: BuLi / tetrahydrofuran / -78 °C 1.2: tetrahydrofuran / 16 h / 20 °C 2.1: 81 percent / HCl |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 4 steps 1.1: BuLi / tetrahydrofuran / -78 °C 1.2: tetrahydrofuran / 16 h / 20 °C 2.1: 81 percent / HCl 3.1: 73 percent / Pd(Ph3P)4; aq. Na2CO3 / toluene / 4 h / 100 °C 4.1: 90 percent / aq. NaOH / methanol; dioxane |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 3 steps 1.1: BuLi / tetrahydrofuran / -78 °C 1.2: tetrahydrofuran / 16 h / 20 °C 2.1: 81 percent / HCl 3.1: 73 percent / Pd(Ph3P)4; aq. Na2CO3 / toluene / 4 h / 100 °C |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 5 steps 1.1: BuLi / tetrahydrofuran / -78 °C 1.2: tetrahydrofuran / 16 h / 20 °C 2.1: 81 percent / HCl 3.1: 73 percent / Pd(Ph3P)4; aq. Na2CO3 / toluene / 4 h / 100 °C 4.1: 90 percent / aq. NaOH / methanol; dioxane 5.1: (COCl)2; DMF / CH2Cl2 |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 6 steps 1.1: BuLi / tetrahydrofuran / -78 °C 1.2: tetrahydrofuran / 16 h / 20 °C 2.1: 81 percent / HCl 3.1: 73 percent / Pd(Ph3P)4; aq. Na2CO3 / toluene / 4 h / 100 °C 4.1: 90 percent / aq. NaOH / methanol; dioxane 5.1: (COCl)2; DMF / CH2Cl2 6.1: Et3N / CH2Cl2; tetrahydrofuran |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 6 steps 1.1: BuLi / tetrahydrofuran / -78 °C 1.2: tetrahydrofuran / 16 h / 20 °C 2.1: 81 percent / HCl 3.1: 73 percent / Pd(Ph3P)4; aq. Na2CO3 / toluene / 4 h / 100 °C 4.1: 90 percent / aq. NaOH / methanol; dioxane 5.1: (COCl)2; DMF / CH2Cl2 6.1: Et3N / CH2Cl2; tetrahydrofuran |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 2 steps 1: Pd(OAc)2; n-Bu4NCl; KOAc / dimethylformamide / 150 °C 2: H2 / 10 percent Pd/C / methanol / 20 °C |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 3 steps 1: Pd(OAc)2; n-Bu4NCl; KOAc / dimethylformamide / 150 °C 2: H2 / 10 percent Pd/C / methanol / 20 °C 3: (PhSeO)2O / tetrahydrofuran / 50 °C |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 4 steps 1: Pd(OAc)2; n-Bu4NCl; KOAc / dimethylformamide / 150 °C 2: H2 / 10 percent Pd/C / methanol / 20 °C 3: (PhSeO)2O / tetrahydrofuran / 50 °C 4: Pd(OAc)2; AcOH / Heating |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 4 steps 1: Pd(OAc)2; n-Bu4NCl; KOAc / dimethylformamide / 150 °C 2: H2 / 10 percent Pd/C / methanol / 20 °C 3: (PhSeO)2O / tetrahydrofuran / 50 °C 4: CeCl3*7H2O; NaIO3 / 2-methyl-propan-2-ol / 40 °C |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 6 steps 1: nBuLi 2: SOCl2 3: NaN3 / toluene 4: toluene / Heating 5: 1 N NaOH / CH2Cl2 6: hydrogen / Pd/C |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 9 steps 1: nBuLi 2: SOCl2 3: NaN3 / toluene 4: toluene / Heating 5: 1 N NaOH / CH2Cl2 6: hydrogen / Pd/C 7: 29 percent / K2CO3 / dimethylformamide 8: 55 percent / NaH / dimethylformamide 9: 1 N HCl / methanol |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 7 steps 1: nBuLi 2: SOCl2 3: NaN3 / toluene 4: toluene / Heating 5: 1 N NaOH / CH2Cl2 6: hydrogen / Pd/C 7: 29 percent / K2CO3 / dimethylformamide |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 8 steps 1: nBuLi 2: SOCl2 3: NaN3 / toluene 4: toluene / Heating 5: 1 N NaOH / CH2Cl2 6: hydrogen / Pd/C 7: 29 percent / K2CO3 / dimethylformamide 8: 55 percent / NaH / dimethylformamide |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 10 steps 1: nBuLi 2: SOCl2 3: NaN3 / toluene 4: toluene / Heating 5: 1 N NaOH / CH2Cl2 6: hydrogen / Pd/C 7: 29 percent / K2CO3 / dimethylformamide 8: 55 percent / NaH / dimethylformamide 9: 1 N HCl / methanol 10: 44 percent / pyridine / CH2Cl2 |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 3 steps 1: 1.) NaOMe, 2.) CuCl / 1.) MeOH, benzene, RT, 1 h, 2.) pyridine, 120 deg C, 86 h 2: 4N aq. LiOH / methanol; tetrahydrofuran / Ambient temperature 3: oxalyl chloride / CH2Cl2 / 1 h / 35 °C |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 2 steps 1: 1.) NaOMe, 2.) CuCl / 1.) MeOH, benzene, RT, 1 h, 2.) pyridine, 120 deg C, 86 h 2: 4N aq. LiOH / methanol; tetrahydrofuran / Ambient temperature |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 5 steps 1: 1.) NaOMe, 2.) CuCl / 1.) MeOH, benzene, RT, 1 h, 2.) pyridine, 120 deg C, 86 h 2: 4N aq. LiOH / methanol; tetrahydrofuran / Ambient temperature 3: oxalyl chloride / CH2Cl2 / 1 h / 35 °C 4: Et3N / CH2Cl2 / 1.) 0 deg C, 1.5 h, 2.) RT, overnight 5: 4N aq. LiOH / methanol; tetrahydrofuran / Ambient temperature |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 4 steps 1: 1.) NaOMe, 2.) CuCl / 1.) MeOH, benzene, RT, 1 h, 2.) pyridine, 120 deg C, 86 h 2: 4N aq. LiOH / methanol; tetrahydrofuran / Ambient temperature 3: oxalyl chloride / CH2Cl2 / 1 h / 35 °C 4: Et3N / CH2Cl2 / 1.) 0 deg C, 1.5 h, 2.) RT, overnight |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 4 steps 1: 61 percent / dimethylformamide / 24 h / 150 °C 2: 67 percent / NaOH / 2-methoxy-ethanol / 8 h / Heating 3: 81 percent / DCC, DMAP / CH2Cl2 / 5 h / Ambient temperature 4: 57 percent / H2 / 10percent Pd/C / methanol / 24 h / Ambient temperature |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 2 steps 1: 61 percent / dimethylformamide / 24 h / 150 °C 2: 67 percent / NaOH / 2-methoxy-ethanol / 8 h / Heating |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 3 steps 1: 61 percent / dimethylformamide / 24 h / 150 °C 2: 67 percent / NaOH / 2-methoxy-ethanol / 8 h / Heating 3: 81 percent / DCC, DMAP / CH2Cl2 / 5 h / Ambient temperature |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 4 steps 1: (i) iPrMgBr, (ii) O2 2: (KO3S)2NO, aq. KH2PO4 / acetone 3: (i) aq. Na2S2O4, (ii) /BRN= 385737/ 4: H2 / Pd-Al2O3 |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 8 steps 1: (i) iPrMgBr, (ii) O2 2: (KO3S)2NO, aq. KH2PO4 / acetone 3: (i) aq. Na2S2O4, (ii) /BRN= 385737/ 4: H2 / Pd-Al2O3 5: (KO3S)2NO, aq. KH2PO4 / acetone 6: TsNHNH2 / CH2Cl2 7: aq. AcOH / Irradiation 8: H2SO4 |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 7 steps 1: (i) iPrMgBr, (ii) O2 2: (KO3S)2NO, aq. KH2PO4 / acetone 3: (i) aq. Na2S2O4, (ii) /BRN= 385737/ 4: H2 / Pd-Al2O3 5: (KO3S)2NO, aq. KH2PO4 / acetone 6: TsNHNH2 / CH2Cl2 7: aq. AcOH / Irradiation |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 5 steps 1: (i) iPrMgBr, (ii) O2 2: (KO3S)2NO, aq. KH2PO4 / acetone 3: (i) aq. Na2S2O4, (ii) /BRN= 385737/ 4: H2 / Pd-Al2O3 5: (KO3S)2NO, aq. KH2PO4 / acetone |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Multi-step reaction with 6 steps 1: (i) iPrMgBr, (ii) O2 2: (KO3S)2NO, aq. KH2PO4 / acetone 3: (i) aq. Na2S2O4, (ii) /BRN= 385737/ 4: H2 / Pd-Al2O3 5: (KO3S)2NO, aq. KH2PO4 / acetone 6: TsNHNH2 / CH2Cl2 |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
41.ii (ii) (ii) Synthesis of 2-(benzyloxy)-6-(2-n-propylethynyl)naphthalene The reaction was conducted in the same manner as in the step (i) of the Example 31, except for using 2-(benzyloxy)-6-bromonaphthalene synthesised in the step (i) and 1-n-pentyne instead of 1-bromo-4-n-propylbenzene and trimethylsilylacetylene, respectively. The resultant was recrystallized from ethanol to give 2-(benzyloxy)-6-(2-n-propylethynyl)naphthalene. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
10.3 EXAMPLE 10 (3) 1.1 g of the product obtained in the paragraph (2) and 1.0 g of 2-benzyloxy-6-bromonaphthalene are treated in the same manner as described in Example 7-(4). 0.73 g of 3-(6-benzyloxy-2-naphthyl)-5-tert.-butoxymethyl-2-oxazolidone is obtained as colorless crystals. m.p. 151.5°-152° C. (ethyl acetate-isopropyl ether). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
65% | With hydrogenchloride; iodine; magnesium In tetrahydrofuran | P.98 Preparation Example 98 Preparation Example 98 In a four-necked flask equipped with a stirrer and thermometer were added 30 ml of anhydrous tetrahydrofuran and 2.4 g (0.1 mole) of magnesium chips, then a mixture of 3.1 g (10 mmoles) of 2-benzyloxy-6-bromonaphthalene and 30 ml of anhydrous tetrahydrofuran, and a small portion of iodine were added thereto, then heated to 60° C. Thereafter a mixture of 28.2 g (90 mmoles of 2-benzyloxy-6-bromonaphthalene and 270 ml of anhydrous tetrahydrofuran was added dropwise thereto. After the addition the resultant mixture was stirred under reflux for 7 hours, and then cooled to room temperature. To a mixture of 5.3 g (0.12 mole) of acetaldehyde and anhydrous tetrahydrofuran was added the resultant mixture obtained above at 0°-5° C. and stirred at the same temperature for 4 hours. After completion of the reaction, to the resultant mixture was added dropwise 50 ml of 1N hydrochloric acid at 0°-10° C., and then warmed by to room temperature. The resultant mixture was extracted with 300 ml of ethyl ether, the organic layer thus obtained was washed successively with water, 5% aqueous sodium bicarbonate solution and saturated aqueous sodium chloride, dried with anhydrous magnesium sulfate and concentrated under reduced pressure. The resultant residue was subjected to silica gel column chromatography (eluent: toluene/ethyl acetate=20/1) to give 18.1 g of 2-benzyloxy-6-(1-hydroxyethyl)naphthalene (XLV-1) as a white solid [Yield: 65%, m.p. 113°-114° C.]. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
X 1- tert -butyloxycarbonyl-4-hydroxy-4-(6-benzyloxynaphth-2-yl)piperidine Preparation X 1- tert -butyloxycarbonyl-4-hydroxy-4-(6-benzyloxynaphth-2-yl)piperidine Beginning with 5.0 gm (15.9 mMol) 2-bromo-6-benzyloxy-naphthalene and 3.34 gm (16.8 mMol) 1- tert -butyloxycarbonyl-4-piperidone, 2.31 gm (33%) of the title compound were recovered as a white solid by the procedure described in Preparation I. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
In diethyl ether; toluene | 58.1 Example 58 (1) To diethyl ether solution of a Grignard's reagent prepared from 10.0 g of 6-bromo-2-benzyloxynaphthalene, prepared by reacting benzyl chloride with alkali metal 6-bromo-2-naphtholate, were added 7.6 g of 2,5-dibromopyridine, and the atmosphere was substituted with nitrogen. After cooling with ice bath to a temperature below 10°C, 193 mg of dichloro[1,4-bis(diphenylphosphino)butane]palladium(II) were added and sitirred for 1 hour in that conditions and then 2 hours without ice bath. After addition of toluene, the organic phase was washed with water and the solvent was removed. The resulting solid was washed with methanol and dried to obtain 7.5 g of 6-(5-bromopyridine-2-yl)-2-benzyloxynaphthalene. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
27% | With copper(l) iodide; <i>L</i>-proline In dimethyl sulfoxide at 80℃; for 44h; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
50% | With potassium carbonate In acetonitrile for 24h; Reflux; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
15% | Stage #1: 6-benzyloxy-2-bromonaphthalene With iodine; magnesium In tetrahydrofuran for 4h; Reflux; Inert atmosphere; Stage #2: N,N-dimethyl-formamide In tetrahydrofuran at 0 - 20℃; Inert atmosphere; Stage #3: With water; acetic acid In tetrahydrofuran |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Stage #1: 1-(tert-butoxycarbonyl)-L-proline; Diphenylphosphinic chloride With triethylamine In 4-(dicyanomethylene)-2-methyl-6-(p-dimethylaminostyryl)-4H-pyran at 0 - 20℃; for 2h; Stage #2: 6-benzyloxy-2-bromonaphthalene With methyl iodide In tetrahydrofuran at 50℃; for 1h; Heating / reflux; | 1-30 The title compound was prepared as follows : A 0 °C solution of N-(tert-butoxycarbonyl)- L-proline (1.65 g, 7.66 mmol) in DCM (25 mL) was charged with triethylamine (1.07 mL, 7.66 mmol) and diphenylphosphinic chloride (1.44 mL, 7.66 mmol), and allowed to warm to rt over 2 h. The solvent was removed in-vacuo, and the residual was partitioned between ethyl ether and H20. The organic layer was subsequently washed with Na2CO3 (2x) and brine (1 X), dried over Na2SO4, filtered, and concentrated in- vacuo. The residual was dissolved in THF (25 mL) and cooled TO-78 °C. Separately, a suspension of 2-bromo-6-benzyloxynaphthelene (1.20 g, 3.83 mmol) and Mg (0.140 g, 5.75 mmol) in THF (4.8 mL) was heated to 50 °C for 30 min, charged with CH3I (1 drop), maintained at 50 °C for an additional 30 min, heated to reflux for 30 min, cooled to rt, and added dropwise to the cooled mixed anhydride solution, which subsequently was allowed to warm to rt overnight with stirring. The solvent was removed in-vacuo, and the residual was partitioned between CH2CL2 and 1: 1 phosphate buffer: 1M citric acid. The organic layer was subsequently washed with Na2CO3 (2x) and brine (LX), dried over NA2SO4, filtered, and concentrated in-vacuo. The residual was subjected to chromatography (gradient of 95% hexanes: 5% EtOAc to 80% hexanes: 20% EtOAc) to afford the title compound as a white solid; mp 102- 104 °C ; MS (ES) 432.13 (M+1). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Stage #1: 6-benzyloxy-2-bromonaphthalene With magnesium In tetrahydrofuran at 50℃; for 0.5h; Stage #2: With methyl iodide In tetrahydrofuran at 50℃; for 1h; Heating / reflux; Stage #3: symmetric anhydride of Boc-Pro-OH In tetrahydrofuran at -78 - 20℃; | 1-30 The title compound was prepared as follows: A 0° C. solution of N-(tert-butoxycarbonyl)-L-proline (1.65 g, 7.66 mmol) in DCM (25 mL) was charged with triethylamine (1.07 mL, 7.66 mmol) and diphenylphosphinic chloride (1.44 mL, 7.66 mmol), and allowed to warm to rt over 2 h. The solvent was removed in-vacuo, and the residual was partitioned between ethyl ether and H2O. The organic layer was subsequently washed with Na2CO3 (2×) and brine (1×), dried over Na2SO4, filtered, and concentrated in-vacuo. The residual was dissolved in THF (25 mL) and cooled to -78° C. Separately, a suspension of 2-bromo-6-benzyloxynaphthelene (1.20 g, 3.83 mmol) and Mg (0.140 g, 5.75 mmol) in THF (4.8 mL) was heated to 50° C. for 30 min, charged with CH3I (1 drop), maintained at 50° C. for an additional 30 min, heated to reflux for 30 min, cooled to rt, and added dropwise to the cooled mixed anhydride solution, which subsequently was allowed to warm to rt overnight with stirring. The solvent was removed in-vacuo, and the residual was partitioned between CH2Cl2 and 1:1 phosphate buffer: 1 M citric acid. The organic layer was subsequently washed with Na2CO3 (2×) and brine (1×), dried over Na2SO4, filtered, and concentrated in-vacuo. The residual was subjected to chromatography (gradient of 95% hexanes:5% EtOAc to 80% hexanes:20% EtOAc) to afford the title compound as a white solid; mp 102-104° C.; MS (ES) 432.13 (M+1). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
72% | With potassium carbonate at 150 - 160℃; for 2h; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
1: 44% 2: 19% | Stage #1: 6-bromo-naphthalen-2-ol; 4-aza-1-benzylazoniabicyclo<2.2.2>octane chloride With potassium carbonate In ethylene glycol at 140℃; for 4h; Stage #2: With hydrogenchloride In water; ethylene glycol |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
65% | Stage #1: 6-benzyloxy-2-bromonaphthalene With n-butyllithium In tetrahydrofuran at -78℃; for 0.166667h; Stage #2: Triisopropyl borate In tetrahydrofuran at -78℃; for 1.75h; Stage #3: With hydrogenchloride In tetrahydrofuran; water |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
69% | With copper(l) iodide; potassium carbonate; <i>L</i>-proline In dimethyl sulfoxide at 110℃; for 24h; Inert atmosphere; | 4.1.2. General procedure for the synthesis of 1-(6-alkoxynaphthalen-2-yl)piperidin-4-ol (4 or 7) General procedure: In a dry single-neck round bottom flask equipped with septum, appropriate 2-alkyloxy-6-bromonaphthalene (3 or 6; 9.6 mmol, 1 equiv.), copper iodide (3.84 mmol, 0.40 equiv.), L-proline (1.92 mmol, 0.2 equiv.), potassium carbonate (19.2 mmol, 2 equiv.) were taken and the contents were dried under vacuum followed by flushing with nitrogen. 4-Piperidinol (9.6 mmol, 1 equiv.) dissolved in dimethyl sulfoxide (DMSO, 30 mL) was added and the reaction mixture was stirred at 110 °C for 24 h. After completion of the reaction, DMSO was removed by extraction with water and ethyl acetate. The ethyl acetate layer was dried over anhydrous sodium sulfate. The organic solvent was evaporated under reduced pressure to give the product as a light brown solid. The crude product was purified on silica gel by using 8-15% of ethyl acetate in hexanes as eluant to get the products. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
57% | With (R)-1-[(SP)-2-(dicyclohexylphosphino)ferrocenyl]ethyldi-tert-butylphosphine; [Pd(π-cinnamyl)Cl]2; caesium carbonate at 25℃; for 48h; Sealed tube; Inert atmosphere; Glovebox; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
79% | With sodium hydride; lithium iodide In tetrahydrofuran; mineral oil at 50℃; for 8h; Sealed tube; |
