[ CAS No. 2754-41-8 ]

{[proInfo.proName]}
Cat. No.: {[proInfo.prAm]}
2D
Chemical Structure| 2754-41-8
Chemical Structure| 2754-41-8
Structure of 2754-41-8

Quality Control of [ 2754-41-8 ]

Purity: {[proInfo.showProBatch.pb_purity]}

Related Doc. of [ 2754-41-8 ]

SDS

Product Details of [ 2754-41-8 ]

CAS No. :2754-41-8MDL No. :MFCD13704912
Formula :C10H8O6Boiling Point :517.5±50.0°C at 760 mmHg
Linear Structure Formula :-InChI Key :-
M.W :224.17Pubchem ID :14453667
Synonyms :

Computed Properties of [ 2754-41-8 ]

TPSA : 86.7 H-Bond Acceptor Count : 6
XLogP3 : -0.5 H-Bond Donor Count : 0
SP3 : 0.60 Rotatable Bond Count : 0

Safety of [ 2754-41-8 ]

Signal Word:WarningClassN/A
Precautionary Statements:P261-P305+P351+P338UN#:N/A
Hazard Statements:H302-H315-H319-H335Packing Group:N/A
GHS Pictogram:

Application In Synthesis of [ 2754-41-8 ]

  • Upstream synthesis route of [ 2754-41-8 ]

[ 2754-41-8 ] Synthesis Path-Upstream   1~8

  • 1
  • [ 94253-98-2 ]
  • [ 2754-41-8 ]
YieldReaction ConditionsOperation in experiment
82.8% With sulfuric acid; acetic acid In 5,5-dimethyl-1,3-cyclohexadiene at 130℃; for 5.00 h; In a 100 mL three-necked flask equipped with a thermometer, a magnetic stirrer, a water separator, and a condenser tube was added 9.64 g of hydrogenatedEthylbenzene tetracarboxylate, 1mL of concentrated sulfuric acid, 5mL of acetic acid and 50mL of xylene were heated to 130°C. During the reaction, the reaction temperature was maintained at reflux, and the reaction continuously removed water for 5 hours. , cooling down to room temperature, suction filtration, filter cake washed with acetone, dried at room temperature under reduced pressure to give white solid 1,2,4,5-cyclohexane tetracarboxylic acid anhydride 4.80g, yield: 82.8percent.
Reference: [1] Patent: CN108069978, 2018, A. Location in patent: Paragraph 0027; 0033; 0034; 0050; 0058; 0074
  • 2
  • [ 15383-49-0 ]
  • [ 2754-41-8 ]
YieldReaction ConditionsOperation in experiment
97.5% for 1.00 h; Inert atmosphere; Reflux 39.2 g of hydrogenated pyromellitic acid (0.15 mol) having a purity of 99.50percent obtained in the step 1 was added to 500 mL four-necked flask , meanwhile adding 120 g of acetic anhydride (1.18 mol) and heating to reflux under a nitrogen atmosphere ,to carry out Dehydration reaction for 1h. [0026] After the reaction was completed, the solution was cooled to precipitate white crystals and filtered. The filter cake was dried under reduced pressure to obtain 32.5 g of white solid hydrogenated pyromellitic dianhydride. The yield was 97.5percent and the purity of GC was 99.85percent.
80% for 1.00 h; Inert atmosphere; Reflux In a three-necked flask equipped with a thermometer, mechanical stirring, and reflux condenser, 100 g of hydrogenated pyromellitic acid and 800 g of acetic anhydride was refluxed for 1 h under protection of nitrogen. Cool to room temperature to precipitate crystals and separate the crystals.Using 50 g of acetic anhydride and drying, 68.9 g of 1,2,4,5-cyclohexanetetracarboxylic dianhydride was obtained. Yield: 80percent.
Reference: [1] Patent: CN103992330, 2016, B. Location in patent: Paragraph 5-7
[2] Patent: CN108069978, 2018, A. Location in patent: Paragraph 0085; 0086
[3] Patent: DE855400, 1943,
  • 3
  • [ 92298-55-0 ]
  • [ 2754-41-8 ]
YieldReaction ConditionsOperation in experiment
76% at 128℃; for 10.00 h; In a 500mL three-necked bottle equipped with a thermometer, magnetic stirrer, water separator, and condenser28.92g hydrogenated pyromellitic acid ester, 4.3mL concentrated sulfuric acid, 125mL acetic acid heated to 128 °C,During the reaction, the reaction continuously removes low-boiling components and reacts for 10 h. , cooling down to room temperature, suction filtration, filter cake washed with 15mL acetic acid, 120 ° C vacuum drying to yield white solid 1,2,4,5-cyclohexane tetracarboxylic dianhydride 13.22g, yield: 76percent.
Reference: [1] Patent: CN108069978, 2018, A. Location in patent: Paragraph 0036; 0041; 0042; 0066
  • 4
  • [ 89-05-4 ]
  • [ 15383-49-0 ]
  • [ 2754-41-8 ]
Reference: [1] Patent: US2016/137789, 2016, A1
  • 5
  • [ 89-05-4 ]
  • [ 2754-41-8 ]
Reference: [1] Patent: CN108069978, 2018, A
[2] Patent: CN108069978, 2018, A
[3] Patent: CN108069978, 2018, A
[4] Patent: CN108069978, 2018, A
[5] Patent: CN108069978, 2018, A
[6] Patent: CN108069978, 2018, A
[7] Patent: CN108069978, 2018, A
  • 6
  • [ 6634-01-1 ]
  • [ 2754-41-8 ]
Reference: [1] Patent: CN108069978, 2018, A
[2] Patent: CN108069978, 2018, A
  • 7
  • [ 635-10-9 ]
  • [ 2754-41-8 ]
Reference: [1] Patent: CN108069978, 2018, A
  • 8
  • [ 89-32-7 ]
  • [ 2754-41-8 ]
Reference: [1] Patent: CN103992330, 2016, B
