Product Details of [ 13599-12-7 ]

CAS No. :13599-12-7
Formula : C12H12N2O2
M.W : 216.24
SMILES Code : O=C(C1=CC(C2=CC=CC=C2)=NN1)OCC
MDL No. :MFCD03130041
InChI Key :AZZHJDRWBMQEKD-UHFFFAOYSA-N
Pubchem ID :138628

Safety of [ 13599-12-7 ]

GHS Pictogram:
Signal Word:Warning
Hazard Statements:H302-H315-H319-H335
Precautionary Statements:P261-P305+P351+P338

Computational Chemistry of [ 13599-12-7 ] Show Less

Physicochemical Properties

Num. heavy atoms 16
Num. arom. heavy atoms 11
Fraction Csp3 0.17
Num. rotatable bonds 4
Num. H-bond acceptors 3.0
Num. H-bond donors 1.0
Molar Refractivity 60.11
TPSA ?

Topological Polar Surface Area: Calculated from
Ertl P. et al. 2000 J. Med. Chem.

54.98 Ų

Lipophilicity

Log Po/w (iLOGP)?

iLOGP: in-house physics-based method implemented from
Daina A et al. 2014 J. Chem. Inf. Model.

2.02
Log Po/w (XLOGP3)?

XLOGP3: Atomistic and knowledge-based method calculated by
XLOGP program, version 3.2.2, courtesy of CCBG, Shanghai Institute of Organic Chemistry

2.43
Log Po/w (WLOGP)?

WLOGP: Atomistic method implemented from
Wildman SA and Crippen GM. 1999 J. Chem. Inf. Model.

2.25
Log Po/w (MLOGP)?

MLOGP: Topological method implemented from
Moriguchi I. et al. 1992 Chem. Pharm. Bull.
Moriguchi I. et al. 1994 Chem. Pharm. Bull.
Lipinski PA. et al. 2001 Adv. Drug. Deliv. Rev.

1.61
Log Po/w (SILICOS-IT)?

SILICOS-IT: Hybrid fragmental/topological method calculated by
FILTER-IT program, version 1.0.2, courtesy of SILICOS-IT, http://www.silicos-it.com

2.74
Consensus Log Po/w?

Consensus Log Po/w: Average of all five predictions

2.21

Water Solubility

Log S (ESOL):?

ESOL: Topological method implemented from
Delaney JS. 2004 J. Chem. Inf. Model.

-2.96
Solubility 0.239 mg/ml ; 0.00111 mol/l
Class?

Solubility class: Log S scale
Insoluble < -10 < Poorly < -6 < Moderately < -4 < Soluble < -2 Very < 0 < Highly

Soluble
Log S (Ali)?

Ali: Topological method implemented from
Ali J. et al. 2012 J. Chem. Inf. Model.

-3.23
Solubility 0.128 mg/ml ; 0.000592 mol/l
Class?

Solubility class: Log S scale
Insoluble < -10 < Poorly < -6 < Moderately < -4 < Soluble < -2 Very < 0 < Highly

Soluble
Log S (SILICOS-IT)?

SILICOS-IT: Fragmental method calculated by
FILTER-IT program, version 1.0.2, courtesy of SILICOS-IT, http://www.silicos-it.com

-4.24
Solubility 0.0124 mg/ml ; 0.0000574 mol/l
Class?

Solubility class: Log S scale
Insoluble < -10 < Poorly < -6 < Moderately < -4 < Soluble < -2 Very < 0 < Highly

Moderately soluble

Pharmacokinetics

GI absorption?

Gatrointestinal absorption: according to the white of the BOILED-Egg

High
BBB permeant?

BBB permeation: according to the yolk of the BOILED-Egg

Yes
P-gp substrate?

P-glycoprotein substrate: SVM model built on 1033 molecules (training set)
and tested on 415 molecules (test set)
10-fold CV: ACC=0.72 / AUC=0.77
External: ACC=0.88 / AUC=0.94

No
CYP1A2 inhibitor?

Cytochrome P450 1A2 inhibitor: SVM model built on 9145 molecules (training set)
and tested on 3000 molecules (test set)
10-fold CV: ACC=0.83 / AUC=0.90
External: ACC=0.84 / AUC=0.91

Yes
CYP2C19 inhibitor?

Cytochrome P450 2C19 inhibitor: SVM model built on 9272 molecules (training set)
and tested on 3000 molecules (test set)
10-fold CV: ACC=0.80 / AUC=0.86
External: ACC=0.80 / AUC=0.87

No
CYP2C9 inhibitor?

Cytochrome P450 2C9 inhibitor: SVM model built on 5940 molecules (training set)
and tested on 2075 molecules (test set)
10-fold CV: ACC=0.78 / AUC=0.85
External: ACC=0.71 / AUC=0.81

No
CYP2D6 inhibitor?

Cytochrome P450 2D6 inhibitor: SVM model built on 3664 molecules (training set)
and tested on 1068 molecules (test set)
10-fold CV: ACC=0.79 / AUC=0.85
External: ACC=0.81 / AUC=0.87

No
CYP3A4 inhibitor?

Cytochrome P450 3A4 inhibitor: SVM model built on 7518 molecules (training set)
and tested on 2579 molecules (test set)
10-fold CV: ACC=0.77 / AUC=0.85
External: ACC=0.78 / AUC=0.86

No
Log Kp (skin permeation)?

Skin permeation: QSPR model implemented from
Potts RO and Guy RH. 1992 Pharm. Res.

-5.89 cm/s

Druglikeness

Lipinski?

Lipinski (Pfizer) filter: implemented from
Lipinski CA. et al. 2001 Adv. Drug Deliv. Rev.
MW ≤ 500
MLOGP ≤ 4.15
N or O ≤ 10
NH or OH ≤ 5

0.0
Ghose?

Ghose filter: implemented from
Ghose AK. et al. 1999 J. Comb. Chem.
160 ≤ MW ≤ 480
-0.4 ≤ WLOGP ≤ 5.6
40 ≤ MR ≤ 130
20 ≤ atoms ≤ 70

None
Veber?

Veber (GSK) filter: implemented from
Veber DF. et al. 2002 J. Med. Chem.
Rotatable bonds ≤ 10
TPSA ≤ 140

0.0
Egan?

Egan (Pharmacia) filter: implemented from
Egan WJ. et al. 2000 J. Med. Chem.
WLOGP ≤ 5.88
TPSA ≤ 131.6

0.0
Muegge?

Muegge (Bayer) filter: implemented from
Muegge I. et al. 2001 J. Med. Chem.
200 ≤ MW ≤ 600
-2 ≤ XLOGP ≤ 5
TPSA ≤ 150
Num. rings ≤ 7
Num. carbon > 4
Num. heteroatoms > 1
Num. rotatable bonds ≤ 15
H-bond acc. ≤ 10
H-bond don. ≤ 5

0.0
Bioavailability Score?

Abbott Bioavailability Score: Probability of F > 10% in rat
implemented from
Martin YC. 2005 J. Med. Chem.

0.55

Medicinal Chemistry

PAINS?

Pan Assay Interference Structures: implemented from
Baell JB. & Holloway GA. 2010 J. Med. Chem.

0.0 alert
Brenk?

Structural Alert: implemented from
Brenk R. et al. 2008 ChemMedChem

0.0 alert: heavy_metal
Leadlikeness?

Leadlikeness: implemented from
Teague SJ. 1999 Angew. Chem. Int. Ed.
250 ≤ MW ≤ 350
XLOGP ≤ 3.5
Num. rotatable bonds ≤ 7

No; 1 violation:MW<1.0
Synthetic accessibility?

Synthetic accessibility score: from 1 (very easy) to 10 (very difficult)
based on 1024 fragmental contributions (FP2) modulated by size and complexity penaties,
trained on 12'782'590 molecules and tested on 40 external molecules (r2 = 0.94)

2.37

Application In Synthesis of [ 13599-12-7 ]

* All experimental methods are cited from the reference, please refer to the original source for details. We do not guarantee the accuracy of the content in the reference.

  • Downstream synthetic route of [ 13599-12-7 ]

[ 13599-12-7 ] Synthesis Path-Downstream   1~35

  • 1
  • [ 13599-12-7 ]
  • [ 60-34-4 ]
  • 5-Phenyl-2H-pyrazole-3-carboxylic acid N'-methyl-hydrazide [ No CAS ]
  • 2
  • [ 2212-05-7 ]
  • [ 13599-12-7 ]
  • [ 918879-53-5 ]
  • 3
  • [ 122-60-1 ]
  • [ 13599-12-7 ]
  • ethyl 1-(2-hydroxy-3-phenoxypropyl)-3-phenyl-1H-pyrazole-5-carboxylate [ No CAS ]
  • 4
  • [ 125228-75-3 ]
  • [ 13599-12-7 ]
  • [ 918879-55-7 ]
  • 5
  • [ 21407-49-8 ]
  • [ 13599-12-7 ]
  • 2-[2-hydroxy-3-(2-nitro-phenoxy)-propyl]-5-phenyl-2<i>H</i>-pyrazole-3-carboxylic acid ethyl ester [ No CAS ]
  • 6
  • [ 13599-12-7 ]
  • [ 2210-74-4 ]
  • [ 918879-59-1 ]
  • 9
  • [ 122-60-1 ]
  • [ 13599-12-7 ]
  • ethyl 1-(2-hydroxy-3-phenoxypropyl)-3-phenyl-1H-pyrazole-5-carboxylate [ No CAS ]
  • 6-(phenoxymethyl)-2-phenyl-6,7-dihydropyrazolo[5,1-c][1,4]oxazin-4-one [ No CAS ]
  • 10
  • [ 2212-05-7 ]
  • [ 13599-12-7 ]
  • [ 918879-53-5 ]
  • C19H15ClN2O3 [ No CAS ]
  • 11
  • [ 125228-75-3 ]
  • [ 13599-12-7 ]
  • [ 918879-55-7 ]
  • C19H15N3O5 [ No CAS ]
  • 12
  • [ 21407-49-8 ]
  • [ 13599-12-7 ]
  • 2-[2-hydroxy-3-(2-nitro-phenoxy)-propyl]-5-phenyl-2<i>H</i>-pyrazole-3-carboxylic acid ethyl ester [ No CAS ]
  • C19H15N3O5 [ No CAS ]
  • 13
  • [ 13599-12-7 ]
  • [ 2210-74-4 ]
  • [ 918879-59-1 ]
  • C20H18N2O4 [ No CAS ]
  • 14
  • [ 98-86-2 ]
  • CH2=CHMgX [ No CAS ]
  • [ 13599-12-7 ]
  • 16
  • [ 13599-12-7 ]
  • [ 291757-98-7 ]
  • 17
  • [ 13599-12-7 ]
  • 4-benzo[1,3]dioxol-5-ylmethyl-2-(3-methoxy-benzyl)-5-phenyl-2<i>H</i>-pyrazole-3-carboxylic acid [ No CAS ]
  • 18
  • [ 13599-12-7 ]
  • [ 291758-00-4 ]
  • 19
  • [ 13599-12-7 ]
  • 4-(6-chloro-benzo[1,3]dioxol-5-ylmethyl)-2-(3-methoxy-benzyl)-5-phenyl-2<i>H</i>-pyrazole-3-carboxylic acid [ No CAS ]
  • 20
  • [ 13599-12-7 ]
  • [ 291758-01-5 ]
  • 21
  • [ 75-03-6 ]
  • [ 13599-12-7 ]
  • [ 10199-55-0 ]
YieldReaction ConditionsOperation in experiment
42% With lithium hydride; In N,N-dimethyl-formamide; Example 33 2-Ethyl-5-phenyl-2H-pyrazole-3-carboxylic Acid Ethyl Ester To a 0° C. mixture of the above-prepared <strong>[13599-12-7]5-phenyl-2H-pyrazole-3-carboxylic acid ethyl ester</strong> (350 mg, 1.62 mmoles) and iodoethane (260 muL, 3.23 mmoles) in DMF (3 mL) was added neat LiH (spatula tip, excess) under a nitrogen atmosphere. The resulting mixture was warmed up to room temperature and stirred overnight. The crude reaction was cooled to 0° C., quenched with aqueous NH4Cl, diluted with ethyl acetate and enough water to dissolve all solids. The phases were separated, and the organic phase was washed sequentially with water and brine, dried over Na2SO4, filtered, and concentrated in vacuo. The regioisomeric products separated and purified by flash chromatography (silica gel, hexanes/ethyl acetate gradient) to give the title compound (167 mg, 42percent yield, higher Rf in hexanes/ethyl acetate) and the undesired regioisomer (175 mg, 44percent yield) as white solids. 1H NMR (CDCl3, 400 MHz): 7.81 (d, 2H); 7.40 (dd, 2H); 7.29 (dd, 1H); 7.13 (s, 1H); 4.63 (q, 2H); 4.37 (q, 2H); 1.47 (t, 3H); 1.41 (t, 3H).
  • 22
  • [ 94-99-5 ]
  • [ 13599-12-7 ]
  • ethyl 1-(2,4-dichlorobenzyl)-3-phenyl-1H-pyrazole-5-carboxylate [ No CAS ]
YieldReaction ConditionsOperation in experiment
78% With potassium carbonate; In N,N-dimethyl-formamide; at 20℃; General procedure: To a mixture of 5 (105 g, 573 mmol), K2CO3 (119 g, 860 mmol), and DMF (400 mL) was added benzyl bromide (117 g, 687 mmol). After being stirred at room temperature for 15 h, the mixture was poured into water and extracted with EtOAc. The extract was washed with water and brine, dried over MgSO4, and concentrated under reduced pressure. The residue was purified by silica gel chromatography (hexane/EtOAc, 100:1 to 4:1) to give 6 (130 g, 83percent) as a pale yellow oil.
50% With potassium carbonate; In N,N-dimethyl-formamide; at 0 - 30℃; for 15h; A mixture of ethyl 3-phenyl-lH-pyrazole-5-carboxylate (70.0' g) , 2, 4-dichlorobenzyl chloride (69.6 g) , potassium carbonate (53.7 g) and N,N-dimethylformamide (400 ml) was stirred at room temperature for 15 hr, the reaction mixture was concentrated, and the residue was partitioned between water and ethyl acetate. The ethyl acetate layer was washed with water and saturated brine, dried (MgSCU) / and concentrated. The residue was crystallized from ethyl acetate- hexane to give ethyl 1- (2, 4-dichlorobenzyl) -3-phenyl-lH- pyrazole-5-carboxylate (61.0 g, yield: 50percent) as brown crystals, melting point 104-1070C.
  • 23
  • [ 98-86-2 ]
  • [ 95-92-1 ]
  • [ 13599-12-7 ]
YieldReaction ConditionsOperation in experiment
81% To a mixture of potassium tert-butoxide (132 g) and tetrahydrofuran (600 ml) was added dropwise a mixture of acetophenone (100 g) and diethyl oxalate (123 g) , and the mixture was stirred at room temperature for 15 hr. Acetic acid' (119 ml) and hydrazine monohydrate (45.8 g) were added to the reaction mixture, and the mixture was stirred with heating under reflux for 2 hr. After cooling to room temperature,' the reaction mixture was concentrated, and the residue was partitioned between water and ethyl acetate. The ethyl acetate layer was washed with saturated aqueous sodium carbonate solution and saturated brine, dried (MgSCM / and concentrated. The residue was crystallized from diisopropyl ether to give ethyl 3-phenyl-lH-pyrazole-5-carboxylate (145 g, yield: 81percent) as a brown solid.1H-NMR (300 MHz, CDCl3) delta: 1-36 (3 H, t, J = 7.2 Hz), 4.36 (2 H, q, J = 7.2 Hz), 7.10 (1 H, s) , 7.30 - 7.46 (3 H, m) , 7.71 - 7.80 (2 H, m) , 11.86 (1 H, brs) .
  • 24
  • [ 13599-12-7 ]
  • [ 939377-23-8 ]
YieldReaction ConditionsOperation in experiment
52% With sodium hydride; In N,N-dimethyl-formamide; at 0 - 20℃; for 0.833333h; To a mixture of <strong>[13599-12-7]5-phenyl-2H-pyrazole-3-carboxylic acid ethyl ester</strong> (500 mg, 2.31 mmol) in N,N-dimethylformamide (30 mL) at O0C was added sodium hydride (60percent in mineral oil, 110 mg, 2.75 mmol). The mixture was stirred at O0C for 10 minutes and stirred at room temperature for 40 minutes. After the reaction mixture was re-cooled to O0C, 2,2,2- trifluoro-methanesulfonic acid 2,2,2-trifluoro-ethyl ester (500 mg, 2.39 mmol) was added dropwise. The mixture was warmed up to room temperature and stirred overnight. The reaction was quenched carefully with ice water and neutralized with IN aqueous <n="58"/>hydrochloric acid. The mixture was extracted with methylene chloride and the organic layer was dried over sodium sulfate. Filtration and concentration gave a crude which was purified by silica gel chromatography (Isco 12O g column, 10percent ethyl acetate/hexanes) to give 5-phenyl-2-(2,2,2-trifluoro-ethyl)-2H-pyrazole-3-carboxylic acid ethyl ester (360 mg, 52percent) as a white solid. The NMR spectrum obtained on the sample is compatible with its structure.
  • 25
  • [ 13599-12-7 ]
  • [ 106-93-4 ]
  • [ 1101861-35-1 ]
  • ethyl 5-phenyl-1-(2-bromoethyl)-1H-pyrazole-3-carboxylate [ No CAS ]
  • 26
  • [ 13599-12-7 ]
  • [ 179057-19-3 ]
  • 27
  • [ 623-73-4 ]
  • [ 122-78-1 ]
  • [ 13599-12-7 ]
  • ethyl 4-hydroxy-3-phenyl-1H-pyrazole-5-carboxylate [ No CAS ]
  • 33
  • [ 6226-25-1 ]
  • [ 13599-12-7 ]
  • [ 939377-23-8 ]
YieldReaction ConditionsOperation in experiment
52% Preparation of 5-phenyl-2-(2,2,2-trifluoro-ethyl)-2H-pyrazole-3-carboxylic acid To a mixture of <strong>[13599-12-7]5-phenyl-2H-pyrazole-3-carboxylic acid ethyl ester</strong> (500 mg, 2.31 mmol) in N,N-dimethylformamide (30 mL) at 0° C. was added sodium hydride (60percent in mineral oil, 110 mg, 2.75 mmol). The mixture was stirred at 0° C. for 10 minutes and then at room temperature for 40 minutes. After the reaction mixture was re-cooled to 0° C., 2,2,2-trifluoro-methanesulfonic acid 2,2,2-trifluoro-ethyl ester (500 mg, 2.39 mmol) was added dropwise. The mixture was warmed up to room temperature and stirred overnight. The reaction was quenched carefully with ice water and neutralized with 1N aqueous hydrochloric acid. The mixture was extracted with methylene chloride and the organic layer was dried over sodium sulfate. Filtration and concentration gave a crude which was purified by silica gel chromatography (Isco 120 g column, 11percent ethyl acetate/hexanes) to give 5-phenyl-2-(2,2,2-trifluoro-ethyl)-2H-pyrazole-3-carboxylic acid ethyl ester (360 mg, 52percent) as a white solid. The NMR spectrum obtained on the sample is compatible with its structure. A mixture of 5-phenyl-2-(2,2,2-trifluoro-ethyl)-2H-pyrazole-3-carboxylic acid ethyl ester (360 mg, 1.21 mmol) and 1N aqueous sodium hydroxide solution (3.6 mL, 3.6 mmol) in methanol (10 mL) was stirred at room temperature overnight. The reaction mixture was acidified to pH~2 with 1N aqueous hydrochloric acid and concentrated to give 5-phenyl-2-(2,2,2-trifluoro-ethyl)-2H-pyrazole-3-carboxylic acid as an off-white solid, which was directly used in the next step reaction without further purification. LCMS calcd for C12H9F3N2O (m/e) 270, obsd 271 (M+H).
  • 34
  • [ 13599-12-7 ]
  • [ 70-11-1 ]
  • [ 618070-56-7 ]
  • [ 1262202-51-6 ]
  • 35
  • [ 13599-12-7 ]
  • C20H22N4O3S [ No CAS ]


Historical Records

Technical Information

Categories

Related Functional Groups of
[ 13599-12-7 ]

Aryls

Chemical Structure| 192701-73-8

A166403 [192701-73-8]

Methyl 3-(p-tolyl)-1H-pyrazole-5-carboxylate

Similarity: 0.97

Chemical Structure| 70015-76-8

A276690 [70015-76-8]

Ethyl 4-amino-3-phenyl-1H-pyrazole-5-carboxylate

Similarity: 0.90

Chemical Structure| 10250-63-2

A111890 [10250-63-2]

Ethyl 1-methyl-3-phenyl-1H-pyrazole-5-carboxylate

Similarity: 0.89

Chemical Structure| 5071-61-4

A156933 [5071-61-4]

5-Phenyl-1H-pyrazole-3-carboxylic acid

Similarity: 0.89

Chemical Structure| 10250-64-3

A155876 [10250-64-3]

1-Methyl-3-phenyl-1H-pyrazole-5-carboxylic acid

Similarity: 0.79

Esters

Chemical Structure| 192701-73-8

A166403 [192701-73-8]

Methyl 3-(p-tolyl)-1H-pyrazole-5-carboxylate

Similarity: 0.97

Chemical Structure| 70015-76-8

A276690 [70015-76-8]

Ethyl 4-amino-3-phenyl-1H-pyrazole-5-carboxylate

Similarity: 0.90

Chemical Structure| 10250-63-2

A111890 [10250-63-2]

Ethyl 1-methyl-3-phenyl-1H-pyrazole-5-carboxylate

Similarity: 0.89

Chemical Structure| 834869-10-2

A259360 [834869-10-2]

Methyl 3-ethyl-1H-pyrazole-5-carboxylate

Similarity: 0.89

Chemical Structure| 78208-72-7

A277688 [78208-72-7]

Ethyl 3-isopropyl-1H-pyrazole-5-carboxylate

Similarity: 0.88

Related Parent Nucleus of
[ 13599-12-7 ]

Pyrazoles

Chemical Structure| 192701-73-8

A166403 [192701-73-8]

Methyl 3-(p-tolyl)-1H-pyrazole-5-carboxylate

Similarity: 0.97

Chemical Structure| 70015-76-8

A276690 [70015-76-8]

Ethyl 4-amino-3-phenyl-1H-pyrazole-5-carboxylate

Similarity: 0.90

Chemical Structure| 10250-63-2

A111890 [10250-63-2]

Ethyl 1-methyl-3-phenyl-1H-pyrazole-5-carboxylate

Similarity: 0.89

Chemical Structure| 5071-61-4

A156933 [5071-61-4]

5-Phenyl-1H-pyrazole-3-carboxylic acid

Similarity: 0.89

Chemical Structure| 834869-10-2

A259360 [834869-10-2]

Methyl 3-ethyl-1H-pyrazole-5-carboxylate

Similarity: 0.89
