* Storage: {[proInfo.prStorage]}
CAS No. : | 141-53-7 | MDL No. : | MFCD00013101 |
Formula : | CHNaO2 | Boiling Point : | - |
Linear Structure Formula : | - | InChI Key : | HLBBKKJFGFRGMU-UHFFFAOYSA-M |
M.W : | 68.01 | Pubchem ID : | 2723810 |
Synonyms : |
|
Num. heavy atoms : | 4 |
Num. arom. heavy atoms : | 0 |
Fraction Csp3 : | 0.0 |
Num. rotatable bonds : | 0 |
Num. H-bond acceptors : | 2.0 |
Num. H-bond donors : | 0.0 |
Molar Refractivity : | 7.14 |
TPSA : | 40.13 Ų |
GI absorption : | Low |
BBB permeant : | No |
P-gp substrate : | Yes |
CYP1A2 inhibitor : | No |
CYP2C19 inhibitor : | No |
CYP2C9 inhibitor : | No |
CYP2D6 inhibitor : | No |
CYP3A4 inhibitor : | No |
Log Kp (skin permeation) : | -6.86 cm/s |
Log Po/w (iLOGP) : | -12.45 |
Log Po/w (XLOGP3) : | -0.2 |
Log Po/w (WLOGP) : | -1.63 |
Log Po/w (MLOGP) : | -1.13 |
Log Po/w (SILICOS-IT) : | -0.23 |
Consensus Log Po/w : | -3.13 |
Lipinski : | 0.0 |
Ghose : | None |
Veber : | 0.0 |
Egan : | 0.0 |
Muegge : | 2.0 |
Bioavailability Score : | 0.55 |
Log S (ESOL) : | -0.14 |
Solubility : | 49.8 mg/ml ; 0.732 mol/l |
Class : | Very soluble |
Log S (Ali) : | -0.19 |
Solubility : | 44.3 mg/ml ; 0.651 mol/l |
Class : | Very soluble |
Log S (SILICOS-IT) : | 0.97 |
Solubility : | 639.0 mg/ml ; 9.4 mol/l |
Class : | Soluble |
PAINS : | 0.0 alert |
Brenk : | 1.0 alert |
Leadlikeness : | 1.0 |
Synthetic accessibility : | 1.07 |
Signal Word: | Warning | Class: | N/A |
Precautionary Statements: | P261-P264-P271-P280-P302+P352-P304+P340-P305+P351+P338-P312-P362-P403+P233-P501 | UN#: | N/A |
Hazard Statements: | H315-H319-H335 | Packing Group: | N/A |
GHS Pictogram: |
* All experimental methods are cited from the reference, please refer to the original source for details. We do not guarantee the accuracy of the content in the reference.
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
87.4% | Stage #1: at 45 - 65℃; for 1.38333 h; Inert atmosphere |
Example 1; The reaction solution with formaldehyde:acetaldehyde:alkaline=5.0:1:1.2 was prepared by dropping alkaline solution (32percent) into the formaldehyde solution (12percent) in 3 minutes after the pressure was stand at 0.2 Mpa by N2 and the initial temperature is at 45 t, then adding acetaldehyde solution (99percent) in 80 minutes, and keeping the final temperature at 65° C. during the feeding by cycle cooling water. Thereafter, the solution was neutralized to pH=6 with formic acid, removed the redundant formaldehyde and methanol, crystallization solution was obtained by evaporation concentration, then pentaerythritol containing 91percent monopentaerythritol was obtained with a single pass yield of 94.2percent. Monopentaerythritol (98.3percent) product was obtained by recrystallized the above pentaerythritol. The centrifuged mother liquor was filter, the filter residue was cascade dissolved-crystallized twice to obtain dipentaerythritol (93.3percent). Rude sodium formate was obtained by concentrating crystallizing filtrate. The filtrate therefrom was diluted to time by water, then heated to dissolve, crystallized and centrifuged to overcome pentaerythritol. The mother liquor after overcoming pentaerythritol was return to overcome rude sodium formate again. The rude sodium formate was recrystallize to obtained sodium formate product with concentration of 96.5percent. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
94% | Stage #1: at 85℃; Stage #2: With hydroxyammonium sulfate In formic acid at 85℃; for 5 h; |
The 3-hydroxy-4-methoxybenzonitrile solution used as a starting material was obtained as follows:- 3-Hydroxy-4-methoxybenzaldehyde (36.7 kg) and sodium formate (30.6 kg) were added to formic acid (96percent, 204 kg) and the resultant mixture was heated to approximately [85°C.] Hydroxylamine sulphate (21.6 kg) was added in eight equal portions at 30 minute intervals and the mixture was heated to [85°C] for 5 hours. The resultant mixture was cooled to approximately [25°C] and added to a solution of sodium chloride (140 kg) in water (700 litres). The resultant solid was collected by filtration, washed with water and dried to give 3-hydroxy- 4-methoxybenzonitrile (34 kg, 94percent; Chemical Abstracts Registry Number 52805-46-6). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
59% | at 110℃; for 6 h; | A mixture of 5-iodoindazole (10 g, 41 mmol) , HCOONa (5.57 g, 82 mmol) and PdCI2(PPh3J2 (1.44 g, 2.05 mmol) in DMF (60 mL) was put under vacuum and charged with carbon monoxide (CO). This process was repeated three times, after which the mixture was kept at 110 0C for 6 hr. After cooling to room temperature (rt), the reaction mixture was diluted with brine and extracted with EtOAc. The organic phases were combined, washed with brine, dried, and concentrated. The crude product was purified by column chromatography to afford 1 H-indazole-5-carboxaldehyde (3.52 g, 59percent) as a white solid. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
89% | at 140℃; for 5h; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
45% | In n-heptane; water at 100℃; for 5h; Yields of byproduct given; | |
In n-heptane; water at 100℃; for 3h; variation of catalyst, organic phase, reaction time; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
13% | To a solution of 2-(bromomethyl)-4,4,5,5-tetramethyl-1,3,2-dioxabororane (1.0 g, 4.5 mmol) in tetrahydrofuran was added sodium formate (462 mg, 6.8 mmol) at room temperature, and the reaction mixture was heated to reflux for 1 hour and 40 minutes under the nitrogen atmosphere. To the reaction mixture was added acetonitrile (10 ml), and the reaction mixture was heated to reflux for 19 hours. After the reaction mixture was cooled at 0C (external temperature), to the reaction mixture was added sodium hydrogen fluoride (1.7 g, 27 mmol), and then, to the reaction mixture was added dropwise water (15 ml) at the same temperature. After the reaction mixture was raised to room temperature, the solvent was distilled off under reduced pressure. To the resulting residue was added acetone (25 ml), and the mixture was heated, allowed to cool at around 40C (internal temperature), and filtered. The solvent was distilled off from the filtrate under reduced pressure, and the residue was washed with ethyl acetate to obtain the title compound (90 mg, 0.60 mmol, 13%). 1H-NMR Spectrum (DMSO-d6) delta (ppm): 3.15(2H, d, J=4.8 Hz), 8.07 (1H, s). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
54% | With acetic anhydride; lithium chloride In N,N-dimethyl-formamide at 80℃; for 16h; | 25 The methyl N-(2,6-dichlorobenzoyl)-4-[(5,6,7,8-tetrahydro-l,8-naphthyridin-3- ylmethyl)amino]carbonyl}-L-phenylalaninate used as the starting material was prepared as follows: To a solution of N-(2,6-dichlorobenzoyl)-0-[(trifluoromethyl)sulfonyl]-L- tyrosinate (400 mg, 0.8 mmol) in DMF (2 ml) were added sodium formate (171 mg, 2.51 mmol), dppp (35 mg, 0.084 mmol), Palladium(II) acetate (19 mg, 0.084 mmol), DIPEA (291 μl, 1.67 mmol), acetic anhydride (177 μl, 1.67 mmol) and LiCl (105 mg, 2.51 mmol). Nitrogen was bubbled through before the reaction mixture was heated at 80°C for 16 hours. After filtration, the residue was purified by Cl 8 reverse phase chromatography (basic conditions) to give 4-{(2S)-2-[(2,6-dichlorobenzoyl)amino]-3-methoxy-3-10 oxopropyl}benzoic acid as a white solid (180 mg, 54%); 1H NMR Spectrum: (DMSO-d6) 3.02 (dd, IH) 3.22 (dd, IH), 3.67 (s, 3H), 4.80 (ddd, IH), 7.38-7.48 (m, 5H), 7.85 (m, 2H), 9.22 (d, IH). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
With macroporous strong acid cation-exchange resin, Purolite C160 In water at 20 - 50℃; | 1; 2; 3 Example 1. KFo production with strong cation exchanger The test was made in smb-pilot system which consists of 20 ion exchange columns, wherein bed height was 1. 5 m and diameter was 0.1 m. The columns were packed with a macroporous strong acid cation-exchange resin, Purolite C160. The switch time of smb-unit was 330 s and the number of switches was 80. During one switch 1. [5 I] sodium formate (concentration 9.6 [MOL/L,] average flow rate 0. 27 I/min and temperature 50 [C)] and 7.1 [1] potassium chloride (concentration 3.9 [MOL/L,] sodium content 2.5 mole- %, average flow rate 1.3 I/min and temperature [20C)] was fed to the smb-unit. In addition to that water was fed for washing. Figure 2 illustrates the column configuration. Sodium formate was fed to the column 4 and potassium chloride to the column 15. The production outlet was from column 9 and regeneration outlet was from column 19. Figure 7 illustrates the percentage of counter ions in each column and Figure 8 illustrates concentration profiles in solution. The profiles are calculated with simulation model. The results are presented in Table 1. The production during one switch was 13.5 mole potassium formate, which sodium content was 9 mole-%. The regeneration product content was 51 mole-% sodium chloride and 49 mole-% potassium chloride. It was noticed that by taking side stream out from the production side the resin utilization can be improved and potassium content of the regeneration outlet (=potassium loss) can be reduced without diminishing the product quality. The switch time was 330 s and the number of switches was 80. During one switch 3.7 [I] sodium formate (concentration 9.6 [MOL/L,] average flow rate 0. 67 I/min and temperature 50 [°C)] and 7.0 [I] potassium chloride (concentration 3.9 [MOL/L,] sodium content 2.5 mole-%, flow rate 1. 3 I/min and temperature [20°C)] was fed to the smb-unit. In addition to that water was fed for washing. Figure 3 illustrates the column configuration. Sodium formate was fed to the column 2 and potassium chloride to the column 14. The production outlet was from column 9 and side stream outlet was from column 5 and regeneration outlet was from column 19. Figure 9 and 10 illustrate the resin and solution profiles. The difference of resin utilization can be seen comparing Figures 7 and 9. The production during one switch was 14.3 mole potassium formate (sodium content 9 mole-%). The side stream product was 12.5 mole potassium formate (sodium content 51 mole-%, which can be reduced by after treatment to 25 mole-%). The regeneration product content was 82 mole-% sodium chloride and 18 mole-% potassium chloride. The sidestream taken out contains thus sodium formate and potassium formate. This mixture can be a final product. The salts can also be separated by crystallization, whereby sodium formate crystals are sepa- rated and recycled as raw material for the production step. The other product is potassium formate solution having a lowered sodium formate content. Smb-unit can be run so, that resin liquid ratio is higher in the middle of system (the end part of the production section and the forepart of the regeneration section) than elsewhere in the system. This can be arranged by switching columns as shown in Figure 4a. Figure 4a illustrates a configuration where resin liquid ratio is 1.5 times higher in the middle of the smb-unit. With this system same benefits as in side stream system (mentioned in Example 2) can be achieved without taking a separate side stream. In the simulation model the situation can be imitated by taking out liquid from the production section and feeding liquid to the regeneration section. The simulation run described below differs from the actual arrangement of Fig. 4 in that respect. In the simulation run the number of columns [WAS 24.] The switch time was 330 s and the number of switches was 96. During one switch 3. [41] sodium formate (concentration 9.1 [MOL/L,] average flow rate 0.62 I/min and temperature 50 [°C)] and 7. [31] potassium chloride (concentration 4.1 [MOL/L,] sodium content 2.5 mole-%, average flow rate 1.3 [I/MIN] and temperature [20°C)] was fed to the smb-unit. In addition to that water was fed for washing. Sodium formate was fed to the column 2 and potassium chloride to the column 16. The production outlet was from column 11 and regeneration outlet was from column 23. Figure 11 and 12 illustrate the resin and solution profiles. The production during one switch was 26.1 mole potassium formate (sodium content 14 mole-%). The regeneration product content was 81 mole-% sodium chloride and 19 mole-% potassium chloride. | |
With macroporous weak-acid cation exchange resin, Purolite C104E In water at 20 - 50℃; | 4 Example 4. KFo production with weak cation exchanger The test was made in pilot as described in Example 1. A macroporous weak-acid cation exchange resin, [PUROLITE] C104E, was used. The switch time of smb unit was 430 s and the number of switches was 80. During one switch 1.8 [I] sodium formate (concentration 9.6 mol/l, average flow rate 0. 25 I/min and temperature 50 [°C)] and 12.7 [1] potassium chloride (concentration 4.0 [MOL/L,] sodium content 2.5 mole- %, average flow rate 1.8 I/min and temperature [20°C)] was fed to the smb-unit. In addition to that water was fed for washing. The column configuration was same as in example 1. Figure 13 and 14 illustrate the resin and solution profiles. The production during one switch was 18.0 mol potassium formate (sodium content 5 mole-%). The regeneration product content was 41 mole-% sodium chloride and 59 mole-% potassium chloride. | |
With weak-acid cation exchange resin, Purolite C104E; strong acid cation-exchange resin, Purolite C160 In water at 20 - 50℃; | 5 Example 5. KFo production with mixture of strong and weak cation exchanger The test was made in pilot as described in example 1. A 1: 1 mixture of weak-acid cation exchange resin, Purolite C104E, and strong acid cation-exchange resin, Purolite C160 was used. The switch time of smb unit was 430 s. The number of switch was [80.] During one switch 2.7 [I] sodium formate (concentration 9.6 [MOL/L,] average flow rate 0.38 [I/MIN] and temperature 50 [°C)] and 8.3 [1] potassium chloride (concentration 4.0 [MOL/L,] sodium content 2.5 mole- %, average flow rate 1.2 [I/MIN] and temperature [20°C)] was fed to the smb-unit. In addition to that water was fed for washing. The column configuration was same as in example 1. This experiment was made only in pilot, not with model, so the profiles are not presented. The production during one switch was 25.5 mol potassium formate (sodium content 17 mole-%). The regeneration product content was 66 mole-% sodium chloride and 34 mole-% potassium chloride. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
With strong acid cation-exchange resin, Purolite C160 In water at 20 - 50℃; | 8 Example 8. KFo production with strong cation exchanger from potassium sulphate The salts with another anion as chloride can also be used as a raw material. When potassium sulphate is used instead of potassium chloride and the regeneration outlet is sodium sulphate. The switch time was 330 s and the number of switches was 80. During one switch 2.0 [I] sodium formate (concentration 9.1 [MOL/L,] average flow rate 0. 36 I/min and temperature 50 [°C)] and 10. [81] potassium sulphate (concentration 1.2 [MOL/L,] sodium content 2.5 mole-%, average flow rate 2.0 I/min and temperature [80°C)] was fed to the smb-unit. In addition to that water was fed for washing. Sodium formate was fed to the column 2 and potassium sulphate to the column 13. The production outlet was from column 8 and regeneration outlet was from column 19. Figure 19 and 20 illustrate the resin and solution profiles. The product during one switch was 18.0 mol potassium formate (sodium content 8 mole-%). The regeneration product content was sodium sulphate 70 mole-% and potassium sulphate 30 [MOLE-%.] |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
67% | With tetrabutyl-ammonium chloride; sodium carbonate In DMF (N,N-dimethyl-formamide) at 80℃; for 48h; | 16 Methyl 3-(allyloxy)-4-iodobenzoate (2.0 g, 6.28 mmol) is dissolved in DMF (15 ml), treated with Pd(OAc)2 (71 mg, 0.31 mmol), Na2CO3 (1.67 g, 15.7 mmol), sodium formate (427 mg, 6.28 mmol), and n-Bu4NCl.H2O (1.92 g, 6.92 mmol) and stirred at 80° C. for 2 days. The mixture is then filtered, the liquor is diluted with EtOAc (75 ml) and washed with 50% saturated NaCl (4×25 ml) followed by 5% HCl (25 ml). The organic layer is dried (Na2SO4), filtered, and concentrated to a brown oil. The crude material is chromatographed over 50 g slurry-packed silica gel, eluting with 20% EtOAc/hexane. The appropriate fractions are combined and concentrated to afford 797 mg (67%) of methyl 3-methyl-1-benzofuran-6-carboxylate as a pale oil. HRMS (FAB) calcd for C11H10O3+H: 191.0708, found 191.0714 (M+H)+. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
44% | With tetrabutyl-ammonium chloride; sodium carbonate In DMF (N,N-dimethyl-formamide) at 80℃; for 48h; | 17 Methyl 4-(allyloxy)-3-iodobenzoate (587 mg, 1.84 mmol) is combined with Pd(OAc)2 (5%, 20 mg, 0.1 mmol), Na2CO3 (487 mg, 4.6 mmol), sodium formate (125 mg, 1.8 mmol) and n-Bu4NCl.H2O (561 mg, 2.0 mmol) in DMF (5 mL) and heated to 80° C. for 2 days. The mixture is concentrated under high vacuum and partitioned between 50% saturated NaCl (10 mL) and CH2Cl2 (4×10 mL). The combined organics are washed with 5% HCl (10 mL), dried (Na2SO4) and concentrated to a brown oil. The crude material is chromatographed over 15 g slurry-packed silica gel, eluting with 15% EtOAc/hexane. The appropriate fractions are combined and concentrated to afford 153 mg (44%) of methyl 3-methyl-1-benzofuran-5-carboxylate as a white solid. HRMS (FAB) calcd for C11H10O3+H: 191.0708, found: 191.0705 (M+H)+. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
94% | The 3-hydroxy-4-methoxybenzonitrile solution used as a starting material was obtained as follows:- 3-Hydroxy-4-methoxybenzaldehyde (36.7 kg) and sodium formate (30.6 kg) were added to formic acid (96%, 204 kg) and the resultant mixture was heated to approximately [85C.] Hydroxylamine sulphate (21.6 kg) was added in eight equal portions at 30 minute intervals and the mixture was heated to [85C] for 5 hours. The resultant mixture was cooled to approximately [25C] and added to a solution of sodium chloride (140 kg) in water (700 litres). The resultant solid was collected by filtration, washed with water and dried to give 3-hydroxy- 4-methoxybenzonitrile (34 kg, 94%; Chemical Abstracts Registry Number 52805-46-6). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
93% | The apparatus was essentially the same as that described in Example 2. 55.5 g (0.6 mol) propionyl chloride were added dropwise at a temperature [OF 21-] [23C] to a stirred suspension of 42.1 g (0.62 mol) of sodium formate in 90 g acetone under an argon atmosphere. The mixture was stirred at [25C] for 2 hours, then heated for 1 hour at [35C.] A solution of 26.3 g (0.1 mol) [OF 1-(2,] 4, [6-TRIHYDROXYPHENYL)-2- (4'-] [HYDROXYPHENYL)-ETHANONE] and 20.4 g (0.2 mol) triethylamine in 165 g of acetone was added dropwise to the resulting suspension at [20-22C.] The reaction mixture was stirred at [21-22C] for 2 hours. To quench the reaction 50 g of ethanol were then added and the mixture was stirred for a further 30 minutes. To promote the hydrolysis 20 g of 37% aqueous hydrochloric acid were added dropwise and the mixture was allowed stand at room temperature for about 16 hours. The mixture was then heated to about [60C] to remove 303 g of distillate. The lost solvent was replaced with 100 g of ethanol. Then 20 g of 37% aqueous hydrochloric acid were added dropwise, and the mixture heated for a further 90 minutes at about [70C.] 400 g of water were added to the resulting suspension at [75-80C] over 30 minutes. The slurry was cooled, held 1 hour at [10C,] and then filtered. The solid was washed twice with 50 g water to afford 31.5 g of a moist beige-coloured product. This was then dried at [100C/1] mbar (0.1 kPa) for 2 hours to afford 25.5 g of an off-white product. HPLC analysis indicated that this consisted of [98.] 3% by weight of genistein. The calculated yield of genistein was 93%. 20 g of the crude genistein product were dissolved in 600 g of ethanol at reflux temperature. Then 470 g of ethanol were distilled off under atmospheric pressure and 130 g of water were added dropwise at [75-80C.] The resulting suspension was cooled to [0C] and stirred one hour at this temperature, then filtered. The filter cake was washed with 20 g of 50% aqueous ethanol, then dried at [100C/1] mbar (0.1 kPa) for 2 hours to afford 19 g of a white product. HPLC analysis indicated that this consisted of 99.1 % by weight of genistein. The yield of genistein after this further purification was 95.7%. | |
92.2% | The apparatus was essentially the same as that described in Example 1, the reactor having a capacity of 500 ml, however. 46.3 g (0.5 mol) of propionyl chloride were added dropwise to a stirred suspension of 35.7 g (0.52 mol) of sodium formate and 26.3 g (0.1 mol) [OF 1-(2,] 4,6- [TRIHYDROXYPHENYL)-2-] [(4'-HYDROXYPHENYL)-ETHANONE] in 180 g of acetone at a temperature of [21-23] C under an argon atmosphere. The mixture was stirred at [23-25C] for 1 hour, and then heated for 1 hour at [35C.] To the suspension at [18-20C] were added 10.1 g (0.1 mol) triethylamine. The reaction mixture was stirred at [21-22C] for 2 hours and then heated 1 hour at [35C.] To quench the reaction 50 g of ethanol were then added and the mixture was stirred for a further 15 minutes. To promote the hydrolysis 20 g of 50% sulphuric acid were added dropwise to the suspension, which was then heated to about [60C] to remove 215 g of distillate. The lost solvent was replaced with [80] g of ethanol. Then a further 15 g of concentrated sulphuric acid were added dropwise, and the mixture heated for a further 90 minutes at about [70C.] 350 g of water were added to the mixture over 30 minutes. The resulting slurry was cooled, held 1 hour at [10C,] and filtered. The collected solid was washed twice with 40 g water and then with 40 g of 50% aqueous ethanol to afford 31 g of a moist beige- coloured product. This was then dried at [100C/1] mbar (0.1 kPa) for 2 hours to afford 25.3 g of an off-white product, which according to HPLC analysis consisted of 98.4% by weight of genistein. The calculated yield of genistein was 92.2%. 20 g of the crude genistein product were suspended in 120 g of 35% aqueous ethanol, and the suspension was stirred at reflux temperature for 2 hours. The resulting slurry was cooled down to [0C,] stirred for 1 hour at that temperature and filtered. The collected solid was washed with 20 g of 35% aqueous ethanol and then dried at [100C/1] mbar (0.1 kPa) for 2 hours to afford 19.5 g of an off-white product. HPLC analysis indicated that this consisted of 99% by weight of genistein. The yield of genistein after this further purification was 98%. | |
92.7% | The apparatus was the same as that described in Example 1. 27.8 g (0.3 mol) of propionyl chloride were added dropwise to a suspension of 21.1 g (0.31 mol) of sodium formate and 13.1 g (0.05 mol) [OF 1-(2,] 4,6-trihydroxyphenyl)- [2- (4'-HYDROXYPHENYL)-ETHANONE] in 100 g of ethyl formate at a temperature [OF 23-26C] under argon. The suspension was stirred for 2 hours at [25C] and heated for 1 hour at [35C.] 10.2 g (0.1 mol) of triethylamine were added to the resulting mixture at an internal temperature of [18-22C.] The mixture was then stirred for 16 hours at room temperature. Then 20 g of ethanol were added and the suspension was stirred for 15 minutes. Thereafter, to promote the hydrolysis, 20 g of 50% sulphuric acid were added dropwise and the mixture was heated to about [80C] to remove 128 g of distillate. The lost solvent was replaced with 50 g of ethanol. 150 g of water were added over 30 minutes to the mixture. The resulting slurry was cooled, held for 1 hour at [10C,] and then filtered. The solid was washed twice with 25 g water and then with 30 g of 50% aqueous ethanol to afford 13.6 g of a moist beige-coloured product. This was then dried at [100C/1] mbar (0.1 kPa) for 2 hours to afford 12.7 g of a beige-coloured product. HPLC analysis indicated that this consisted of 98.7% by weight of genistein. The yield of genistein was 92.7%. |
79.4% | The apparatus was the same as that described in Example 2. 60 g (0.65 mol) of propionyl chloride were added dropwise to a stirred suspension of 51 g (0.75 mol) of powdered sodium formate and 26.3 g (0.1 mol) of [1- (2,] 4,6- [TRIHYDROXYPHENYL)-2- (4'-HYDROXYPHENYL)-ETHANONE] in 200 g of acetone at a temperature of [21-23C.] The suspension was stirred at [23-25C] for 30 minutes, then heated for 13 hours at [32C.] Thereafter, to promote the hydrolysis, 50 g of 50% sulphuric acid were added dropwise at [10-12C] and the mixture was heated to about [60C] to remove 204 [G] of distillate. The lost solvent was replaced with 120 g of ethanol. Then a further 25 g of 50% sulphuric acid were added dropwise, and the mixture heated for a further 1 hour at about [72C.] To the mixture was added over 30 minutes 300 g of water. The slurry was cooled, held for 1 hour at [30C] and then filtered. The solid was washed twice with 40 g of water and once with 50 g of 50% aqueous ethanol. This was then dried at [100C/1] mbar [(0. 1] kPa) for 2 hours to afford 21.6 g of a white product. HPLC analysis indicated that this consisted of 99.3% by weight of genistein. The yield of genistein was 79.4%. | |
79.5% | The apparatus was the same as that described in Example 1. 27.8 g (0.3 mol) of propionyl chloride were added dropwise to 21.1 g (0.31 mol) of sodium formate at a temperature of [23-25C] under argon. The white suspension was stirred 2 hours at [25C] and heated for 1 hour at [35C.] To this mixture were added 13.1 g (0.05 mol) [OF 1-(2,] 4, [6-TRIHYDROXYPHENYL)-2- (4'-HYDROXYPHENYL)-ETHANONE] and 10.2 g (0.1 mol) of triethylamine at an internal temperature of 20-22C. The mixture was then stirred at [21-22C] for 2 hours and heated for 2 hours at [35C.] 50 g of ethanol were added at [20C,] and the suspension was stirred for 15 minutes. Thereafter, to promote the hydrolysis, 30 g of 50% sulphuric acid were added dropwise and the mixture was heated for 1 hour at [75C.] To the mixture were then added over 30 minutes 150 g of water. The resulting slurry was cooled, held for 1 hour at [10C,] and then filtered. The solid was washed twice with 20 g water then with 30 g of 50% aqueous ethanol to afford 13.6 g of a moist beige-coloured product. This was then dried at [100C/1] mbar (0.1 kPa) for 2 hours to give 10.9 g of a beige-coloured product. HPLC analysis indicated that this consisted of 98.4% by weight of genistein. The yield of genistein was 79.5%. | |
77% | The apparatus was the same as that described in Example 1. 27.8 g (0.3 mol) of propionyl chloride were added dropwise to a stirred suspension of 21.1 g (0.31 mol) of sodium formate and 13.1 g (0.05 mol) [OF 1-(2,] 4,6- [TRIHYDROXYPHENYL)-2- (4'-HYDROXYPHENYL)-ETHANONE] in 100 g of dimethylformamide at a temperature [OF 25-28C] under an argon atmosphere. The mixture was stirred at [25C] for 2 hours and then heated for 2 hours at [35C.] To quench the reaction 15 g of ethanol were then added and the mixture was stirred for a further 15 minutes. To promote the hydrolysis, 20 g of 50% sulphuric acid were added dropwise to the suspension at room temperature, and the reaction mixture was distilled in vacuo at [80] mbar (8 kPa) and [70-80C] to remove 75 g of solvent. Then a further 20 g of concentrated sulphuric acid were added dropwise, and the mixture was heated for a further hour at [80C.] To the mixture was added 150 g of water, which promoted crystallization. The resulting slurry was cooled, held for an hour at [10C,] and then filtered. The collected solid was washed twice with 25 g of water and once with 30 g of 50% aqueous ethanol. The solid was then dried at [100C/1] mbar (0.1 kPa) for 2 hours to afford 10.5 g of an off-white product. HPLC analysis indicated that this consisted of 98.2% by weight of genistein. The yield of genistein was 77%. | |
67.5% | The apparatus was the same as that described in Example [1.] A suspension of 21.1 g (0.31 mol) of sodium formate, 13.1 g (0.05 mol) of 1- (2,4, [6-TRIHYDROXYPHENYL)-2- (4'-HYDROXYPHENYL)-ETHANONE] and 6.9 g (0.05 mol) potassium carbonate in 100 g of acetone was stirred 1 hour at [25C] under argon. To this mixture were added dropwise 27. [8] g (0.3 mol) of propionyl chloride at a temperature [OF 21-23C.] The suspension was stirred for 16 hours at room temperature. Then 20 g of ethanol were added, and the suspension was stirred for 15 minutes. Thereafter, to promote the hydrolysis, 20 g of 50% sulphuric acid were added dropwise and the mixture was heated to about [60C] to remove the solvent. The lost solvent was replaced with 50 g of ethanol. Then a further 10 g of concentrated sulphuric acid were added dropwise, and the mixture heated for a further hour at about [80C.] To the mixture was added over 30 minutes 120 g of water. The slurry was cooled, held for 1 hour at [10C] then filtered. The solid was washed twice with 20 g water and then with 30 g of 50% aqueous ethanol. This was then dried at [100C/1] mbar (0.1 kPa) for 2 hours to give 9.3 g of a pale yellow product. HPLC analysis indicated that this consisted of 97.8% by weight of genistein. The yield of genistein was 67.5%. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
90.3% | The apparatus was the same as that described in Example 2. 54.4 g (0.5 mol) of isobutyryl chloride were added dropwise under argon to a suspension of 35.7 g (0.51 mol) of sodium formate and 26.3 g (0.1 mol) [OF 1-(2,] 4,6- trihydroxyphenyl)-2- (4'-hydroxyphenyl)-ethanone in 150 g of acetone at a temperature of [21-23C.] The suspension was stirred for 1 hour at [23-25C] and heated for 2 hours at 30- [32C.] To the resulting mixture were added 15.2 g (0.15 mol) of triethylamine at an internal temperature of [18-22C.] The mixture was then stirred for 1 hour at [21-22C] and heated at [30-32C] for 1 hour. Thereafter, to promote the hydrolysis, 50 g of 50% sulphuric acid were added dropwise and the mixture was heated to about [60C] to remove 148 g of distillate. The lost solvent was replaced with 120 g of ethanol. The mixture was heated for a further 3 hours at about [70C.] To the suspension were added over 30 minutes 350 g of water. The resulting slurry was cooled, held for 1 hour at [30C,] and then filtered. The solid was washed twice with 40 g water and once with 50 g of 50% aqueous ethanol to afford 31.6 g of a moist off- white product. This was then dried at [100C/1] mbar (0.1 kPa) for 2 hours to afford 24.5 g of an off-white product. HPLC analysis indicated that this consisted of 99.6% by weight of genistein. The yield of genistein was 90.3%. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
40% | In dimethyl sulfoxide; acetonitrile at 120℃; for 0.5h; | 2.e e) Preparation of N-(4-ethoxy-6-formyl-quinolin-2-yl)-acetamide A mixture of tetrakis(triphenylphosphine)palladium (Pd(PPh3)4) and sodium formate (5 g, 48 mmol) in acetonitrile (30 ml) was purged with nitrogen. A solution of N-(6-bromo-4-ethoxy-quinolin-2-yl)-acetamide (2.5 g, 8.12 mmol) in DMSO (30 mL) was added through a rubber septum. The vessel was put under an atmosphere of carbon monoxide (50 psi), sealed and heated to 120° C. for 30 min. The mixture was cooled to rt and the acetonitrile was evaporated under reduced pressure. Water was added and the resulting precipitate was collected by filtration and dried to afford the desired aldehyde N-(4-ethoxy-6-formyl-quinolin-2-yl)-acetamide as a pale yellow solid (0.8 g, 40%). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
91% | In N,N-dimethyl-formamide at 110℃; for 2h; | A.4.b CO (gas) was bubbled through a mixture of intermediate compound 13 (prepared ac- cording to A4.a) (0.00022 mol), NaHCO2 (0.00033 mol) and Cl2Pd(PPh3)2 (0.000009 mol) in DMF (5 ml), then the reaction mixture was heated to 110 °C with CO (gas) still bubbling through. Extra NaHCO2 (2 x q.s.) and Cl2Pd(PPh3)2 (2 x q.s.) were added and the mixture was heated for 2 hours at 110 °C with CO (gas) bubbling through. The solvent was evaporated and the residue was taken up in CH2Cl2. The sol- ids were filtered off over dicalite and the solvent was evaporated. The obtained residue was purified in a manifold (vacuum) (eluent: CH2Cl2ZCH3OH 96/4). The product frac- tions were collected and the solvent was evaporated. Yield: 0.081 g of intermediate compound 10 (91 %). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
bis-triphenylphosphine-palladium(II) chloride; In N,N-dimethyl-formamide; at 110℃; for 2h; | Intermediate 34; Preparation of (E)-2-chloro-4-(3,3,3-trifluoroprop-1-enyl)benzoic acid; Methyl 2-chloro-4-formylbenzoate A slow stream of CO was passed into a suspension of <strong>[185312-82-7]methyl 4-bromo-2-chlorobenzoate</strong> (1.50 g, 0.00601 mol), bis(triphenylphosphine)palladium(II) chloride (80 mg, 0.0001 mol), sodium formate (613 mg, 0.00902 mol), and dry DMF (10 mL). The mixture was vigorously stirred at 110 C. for 2 h. After cooling, the mixture was treated with aqueous Na2CO3 solution and extracted with EtOAc. The extract was washed with brine, dried (Na2SO4), and concentrated. The residue was chromatographed on silica gel with AcOEt-hexane to give the product as a colorless oil (becomes a white solid when stored in a refrigerator). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
80% | In formic acid; water for 3.5h; Heating / reflux; | |
80% | Stage #1: sodium formate; 10<i>H</i>-phenoxazin-1-ylamine; hydrochloride With formic acid for 3.5h; Heating / reflux; Stage #2: With sodium hydroxide In water at 20℃; for 0.5h; | 6 Synthesis of 2,10b-diaza-6-oxaaceanthrylene (imidazo[4,5,1-k,l]phenoxazine) The preparation is carried out by a method based on those of H. Shirai and T. Hayazaki, Yakugaku Zasshi 90 (1970) 588-593 and A. N. Gritsenko, Z. I. Ermakova, V. S. Troitskaya and S. V. Zhuravlev., Chem. Heterocycl. Compd. 1971, 715-717.18.45 g (78.6 mmol) of 1-ammoniophenoxazine chloride are suspended in 85 ml of 85% strength formic acid. After addition of 5.38 g (78.6 mmol) of sodium formate, the reaction mixture is refluxed for 3.5 hours. After cooling to room temperature, the reaction mixture is precipitated in 700 g of 10% strength NaOH and stirred for another 30 minutes. The solid is filtered off with suction on a “black band” filter, washed with water and dried at 70° C. under reduced pressure. The crude product (16.35 g) is stirred in 160 ml of methanol for 2 hours, subsequently filtered off with suction, washed with methanol and dried at 70° C. This gives 13.09 g (80% of theory) of gray needles which melt at 177-181° C. (lit.: 177-178° C.). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
With sulfuric acid concd. H2SO4; | ||
With sulfuric acid In sulfuric acid | ||
In sulfuric acid anhydrous Na-formate reacted with dild. H2SO4 at sufficiently low temp.;; condensed and fractionatedly distilled;; |
In not given at glowing heat;; | ||
With acetic anhydride; N-ethyl-N,N-diisopropylamine In N,N-dimethyl-formamide at 20℃; for 1h; | 7A.B Part B: A saturated solution of carbon monoxide in a 20 ml scintillation vial was pre- prepared by adding acetic anhydride (0.032 mL, 0.34 mmol) and diisopropylethylamine (0.046 mL, 0.34 mmol) to a solution of sodium formate (0.034 g, 0.51 mmol) in de-gassed DMF (2 mL). The reaction mixture was stirred at room temperature for 1 hour. In another flask, palladium (II) acetate (0.00113 g, 0.005 mmol) was added to a solution of 1 ,3-bis(diphenylphosphino)propane (0.00207 g, 0.005 mmol) in de-gassed DMF (2 mL) and stirred at room temperature for 30 minutes. Lithium chloride (0.021 g, 0.51 mmol) was added and the solution sonicated to ensure there was no precipitation. Compound 330 (0.061 g, 0.17 mmol) was added and the reaction mixture quickly transferred to the saturated solution of carbon monoxide. The vial was capped and the reaction mixture heated at 800C for 16 hours. The vial was cooled to room temperature, and the reaction monitored by LC- MS. The precipitates were removed by filtration, the filtrate concentrated, and the crude re-dissolved in acetonitrile (1 mL). The solution was acidified to pH 4.0 with 1.0 M HCI, concentrated and dried to afford compound 335 which was used as crude in the next step. HPLC-MS tR = 1.85 min (UV254 nm); mass calculated for formula C16H14N2O4S 330.1 , observed LCMS m/z 331.0 (M+H). | |
With H2SO4 In sulfuric acid | ||
In sulfuric acid aq. H2SO4; anhydrous Na-formate reacted with dild. H2SO4 at sufficiently low temp.;; condensed and fractionatedly distilled;; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
86.6% | With nickel; hydrogen In water at 200℃; for 2h; Green chemistry; | |
85.3% | With hydrogen In water at 100℃; for 10h; Autoclave; | |
84% | With RuCl<SUB>2</SUB>((iPr<SUB>2</SUB>PCH<SUB>2</SUB>CH<SUB>2</SUB>)<SUB>2</SUB>NH); hydrogen In water at 150℃; for 18h; | 35.1; 35.2 Example 35.1. Preparation of sodium formate using (0157) RuCfc P^PC Cf^NH] as catalyst Water (10.0 g) was added to a mixture of sodium bicarbonate (2.5 g) and the catalyst (10 mg) in a 100 ml Parr pressure reactor. The mixture was degassed with hydrogen and the pressure was set to 500 psi. The mixture was stirred for 18 hours at 150 SC. It was then cooled to room temperature and the residue evaporated to dryness. The NMR spectra of the solid showed that it is composed of 84% sodium formate and 16% sodium bicarbonate. |
77% | With C57H45N6P2Ru(1+)*CF3O3S(1-); hydrogen In tetrahydrofuran; water at 20 - 130℃; for 25h; Autoclave; Schlenk technique; | |
67% | With hydrogen In water High Pressure; heating at 320°C, 260 atm total pressure;; | |
40.49% | With sodium tetrahydroborate; zinc(II) oxide In water at 90℃; for 6h; | 5 The reduction of sodium bicarbonate was performed using sodium borohydride as reducing agent in the presence of various metal oxide catalyst such as Aeroxide P90 Ti02 CuO and ZnO as catalyst. Initially known quantities of sodium bicarbonate (10 g/l), reducing agent sodium borohydride (10 g/l) and metal oxide catalyst (0.23 w/v%) added into the water (350 ml). The reaction solution was stirred at 650 rpm andsubsequently solution was heated at 90 C & atmospheric pressure for 6 hrs. When the desired reaction temperature (90 C) was reached, then it was considered as the zero reaction time and sample was withdrawn through the sample tube as a zero time sample. Subsequently samples were withdrawn at specific time intervals through the sample tube. Table 5 shows the amount of sodium formate formed during the reduction reaction. |
28.6% | With 5% Pd/C; hydrogen In water at 20℃; for 1h; | |
28.6% | With 5%-palladium/activated carbon; hydrogen In water for 1h; | 1 General procedure: The hydrogenation of bicarbonate was carried out in the Parr micro-reactor, the dehydrogenation of formate was carried out in the reactor illustrated in FIG. 1. The fresh catalyst system after one cycle reaction (bicarbonate hydrogenation and formate dehydrogenation) was noted as spent 1 cycle. After every reaction, the spent catalyst system was separated by centrifugation and washed with water and ethanol 5 times, then dried at 50° C. in N2. The hydrogenation reaction conditions were: 20 mL H2O, 1M concentration of ammonium bicarbonate, 20° C. reaction temperature, 400 psi (H2) reaction pressure, 0.1 g fresh and spent catalyst system loading, 1 hour reaction time. Dehydrogenation reaction conditions were: 20 mL H2O, 1M concentration of ammonium formate, 80° C. reaction temperature, 1 atm (N2) reaction pressure, 0.1 g catalyst system loading, one hour reaction time. In the hydrogenation reaction system using a Pd/AC (5 wt % Pd) nano-catalyst system and 20 mmol NH4HCO3 in 20 ml H2O (NH4HCO3 concentration=1 mol/L), the ability to produce formate was determined. A high yield of ammonium formate, 59.6%, with a TON of 1103 was gained after reacting for 1 hour when the initial H2 pressure was 5.5 MPa. By extending the reaction time to 2 hours, a 90.4% formate yield with a TON of 1672 was obtained. As a side-by-side comparison, a [{RuCl2(benzene)}2] homogeneous catalyst was used under the similar reaction conditions (5 MPa initial H2 pressure and a 2-hour reaction time). Using the [{RuCl2(benzene)}2] homogeneous catalyst a yield of formate 35% with a TON of 807 was gained from 24 mmol NaHCO3 in the solution of 25 ml H2O and 5 ml THF solvent (reagent concentration<1 mol/L). These results indicate that the hydrogen storage process based on the reduction of ammonium bicarbonate over the Pd/AC heterogeneous catalyst system is more efficient than a homogeneous catalyst. |
15% | With [bis(2-methylallyl)cycloocta-1,5-diene]ruthenium(II); (dicyclohexylphosphanyl)(naphthalen-1-yl)methanone; hydrogen In methanol at 20 - 80℃; for 20h; Autoclave; | |
With hydrogen In not given High Pressure; catalyst: Ruffert-Ni on wax, 200°C, 190 atm H2;; | ||
With hydrogen In water High Pressure; at temp. <270°C, high pressure;; | ||
With hydrogen In water High Pressure; at temp. <270°C, high pressure;; | ||
With hydrogen In water High Pressure; at temp. <270°C, high pressure;; | ||
With hydrogen In water High Pressure; heating aq. NaHCO3 soln. with H2 in the presence of Ni on coke (catalyst) in autoclave at 300°C, 300 atm;; | ||
With hydrogen In water Pd catalyst suspended in aq. soln. of NaHCO3, H2 purged slowly; | ||
With H2; catalyst: Fe(BF4)2/P(CH2CH2P(C6H5)2)3 In methanol byproducts: H2O; High Pressure; in autoclave, 30-90 bar H2; stirred (400 rpm) for 20 h at 60-100°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; detected by NMR (D2O/THF); | ||
0% | With H2; cat.: Fe(BF4)2/tris(2-aminoethyl)amine In methanol High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; | |
0% | With H2; cat.: Fe(BF4)2/tris[2-(dimethylamino)ethyl]amine In methanol High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; | |
0% | With H2; catalyst: Fe(BF4)2/1,1,1-tris((C6H5)2P)methane In methanol High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; | |
0% | With H2; catalyst: Fe(BF4)2/1,1,1-tris((C6H5)2PCH2)ethane In methanol High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; | |
0% | With H2; catalyst: Fe(BF4)2/1,1-bis(2-(C6H5)2PC2H4)P(C6H5) In methanol High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; | |
With H2; catalyst: FeCl2/P(CH2CH2P(C6H5)2)3 In methanol byproducts: H2O; High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; detected by NMR (D2O/THF); | ||
With H2; catalyst: [(RuCl2(benzene))2]/P(CH2CH2P(C6H5)2)3 In methanol byproducts: H2O; High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; detected by NMR (D2O/THF); | ||
With H2; catalyst: [Fe(acetylacetonyl)3]/P(CH2CH2P(C6H5)2)3 In methanol byproducts: H2O; High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; detected by NMR (D2O/THF); | ||
0% | With H2; catalyst: [HFe3(CO)11](1-)/P(CH2CH2P(C6H5)2)3 In methanol High Pressure; in autoclave, 60 bar H2; stirred (400 rpm) for 20 h at 80°C, autoclave cooled with ice water and pressure slowly released, soln. fully evapd. in rotary evaporator; | |
88 %Spectr. | With FeH(P(CH2CH2P(C6H5)2)3)(1+)*BF4(1-)=[FeH(P(CH2CH2P(C6H5)2)3)]BF4; hydrogen In methanol at 80℃; for 20h; Autoclave; | |
With H2; catalyst: (RuCl2(benzene))2/dppm In tetrahydrofuran; water 2 h at 70°C at 50 bar H2 or 50 bar H2 and 30 bar CO or at 80 bar H2 and room temp. for 24 h; detd. by NMR; | ||
77 %Spectr. | With [iron(II)-fluoro-tris(2-(diphenylphosphino)phenyl)phosphino]tetrafluoroborate; hydrogen In methanol at 100℃; for 20h; Inert atmosphere; Schlenk technique; Autoclave; | |
With mercury In water Electrochemical reaction; | ||
With (2,6-bis[(di-t-butylphosphino)methyl]phenyl)hydridonickel; hydrogen In methanol at 150℃; for 20h; | ||
44.7 %Spectr. | With triscarbonyl‐(η4–3,4‐bis(4‐methoxyphenyl)‐2,5‐diphenylcyclopenta‐2,4‐dienone)iron; hydrogen In ethanol; water at 120℃; for 24h; Autoclave; | |
100 %Spectr. | With (1,4-dimethyl-5,7-diphenyl-1,2,3,4-tetrahydro-6H-cyclopenta[b]pyrazin-6-one) irontricarbonyl complex3; hydrogen In water; dimethyl sulfoxide at 100℃; for 20h; Autoclave; | |
With {RuCl2(m-triphenylphosphine trisulfonate)2}2; hydrogen; tris-(m-sulfonatophenyl)phosphine In water at 80℃; Autoclave; | ||
With [Fe(H)(Cl)(CO)(2,6-bis(di-tert-butylphosphinomethyl)pyrazine)]; potassium <i>tert</i>-butylate; hydrogen In tetrahydrofuran; water at 45℃; for 16h; Inert atmosphere; | ||
98 %Spectr. | With [Fe(PNP-iPr)(H)(Br)(CO)]; hydrogen In tetrahydrofuran; water at 80℃; for 24h; | |
With hydrogen at 80℃; for 24h; | ||
With hydrogen In water High Pressure; heating aq. NaHCO3 soln. with H2 in the presence of Ni on coke (catalyst) in autoclave at 300°C, 300 atm;; | ||
98 %Spectr. | With (OC-6-52)-[2-[bis(1-methylethyl)phosphino-κP]-N-[2-[bis(1-methylethyl)phosphino-κP]ethyl]ethanamine-κN](carbonyl)(chloro)(hydrido)ruthenium(II); hydrogen In 2-methyltetrahydrofuran; water at 80℃; for 1.63333h; | |
With C89H75N9O2P6Ru2(2+)*2Cl(1-); hydrogen In tetrahydrofuran; water at 130℃; for 0.5h; Autoclave; | ||
With (1,4-dimethyl-5,7-diphenyl-1,2,3,4-tetrahydro-6H-cyclopenta[b]pyrazin-6-one) irontricarbonyl complex3; Cr(3+)*HO(1-)*C8H4O4(2-)*H2O; hydrogen In water; dimethyl sulfoxide at 100℃; for 20h; Autoclave; Inert atmosphere; | ||
With hydrogen In water at 99.84℃; | ||
With C12H32N4NiO(2+)*2NO3(1-); hydrogen In water at 120℃; for 12h; High pressure; | 2.4.6. Hydrogenation reaction procedure Hydrogenation reactions were performed in a high-pressurereactor (250 mL). The solution of NaHCO3 was added into the reactoralong with the catalyst. The reactor was then purged with N2before the introduction of H2 (60 bar at room temperature), andthen heated to the chosen temperature accompanied by stirringat 300 rpm. After a specific period of time, the reactor was cooleddown to room temperature and the pressure released. The productwas analyzed using an Agilent 1200 series (Agilent Technologies,Germany) LC system. The product separation was performed at50 C on a BIORAD AmineX HPX-87H Ion Exclusion Column(300 mm 7.8 mm). The flow rate was maintained at 0.75mL/min, run time was 20 min, and the UV detector was set at220 nm. The injection volume of the sample was 10 lL. The calibrationcurve with R2 of 0.999 was obtained with a series of formatesolutions (0.001 to 0.050 M). | |
With nickel(II) ferrite; hydrogen at 80℃; for 2h; | Catalytic conversion of sodium hydrogen carbonate to sodium formate through hydrogenation in the presence of nickel ferrite catalyst To produce the sodium formate (NaHCO2) from sodium hydrogen carbonate (NaHCO3), the reaction was carried out in a reactor attached with a round bottom flask. Hydrogen gas was produced in the flask by the reaction of zinc metal rings with sulfuric acid. Sodium hydrogen carbonate (100 mL, 1 M) was put into the reactor. Two hundred milligrams of nickel ferrite catalyst was introduced into the reactor; then, the hydrogen gas was bubbled into the sodium hydrogen carbonate solution for 2 h at a temperature of 80° C and at the atmospheric pressure. The solution was stirred at 100 rpm, and after the completion of the reaction, the left solution was evaporated at 105° C for 24 h to obtain the sodium formate attached over the nickel ferrite catalyst surface. This material was then stored in air tight bags until further use. | |
With methanol In water at 180℃; for 16h; | ||
60.3 %Spectr. | With [RuHCl(CO)(2,6-bis[(di-tertbutylphosphino)methyl]pyridine)]; hydrogen; Aliquat 336 In water; toluene at 90℃; for 4.5h; Autoclave; Inert atmosphere; Glovebox; Schlenk technique; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
With alkali In not given react. with bases in presence of moisture or H2O;; | ||
With sodium chalk | ||
With alkali In not given react. with bases in presence of moisture or H2O;; |
12.5 g | With triphenylphosphine; sodium hydroxide; palladium dichloride In water; toluene at 40℃; for 6h; Inert atmosphere; | 2 25.1 g of toluene and 25 g of a 30% aqueous sodium hydroxide solution (0.18811101) were placed in a reaction kettle followed by the addition of 0.33 g (1.86 mmol) of palladium dichloride and 1.95 g ) Triphenylphosphine, closed reaction dad, with nitrogen replacement reactor in the air, stirring heated to 40 ° C, to the kettle filled with carbon monoxide, to keep the pressure in the 0. 2-0. 4MPa between the reaction after 6 hours, The upper layer of toluene (including catalyst) can be used for the next application, the lower water layer evaporation, drying in sodium formate, weight 12.5 grams (according to the sodium hydroxide the idea receives rate 98%),content> 97% |
With sodium hydroxide at 75 - 145℃; | 1 synthesis of sodium formate (1) the air from the bottom of the gas into the furnace,Coke in the furnace combustion gas,The resulting gas is washed in a washing tower,Washing method using two countercurrent washing,Sewage from the bottom of the tower into the pool;(2) gas from the top of the tower by the water ring vacuum pump into the alkali washing tower,With the alkali from the caustic soda backcour full contact,The gas is washed through the tertiary lye,Fully absorb the carbon dioxide in the gas,Hydrogen sulfide,Oxygen sulfide impurities,Wash the resulting sodium carbonate back to the by-product tank for storage,Carbon monoxide gas from the top into the water tower,The purpose is to remove the gas entrained lye and cool down;(3) gas into the gas-liquid separator,Water from the bottom into the water seal,Then back to the circulating pool,In addition to the gas after the gas into the gas compressor pressure,After oil and water separation into the casing after the heat exchanger,Since caustic soda lye with a metering pump into the tank casing,Fully mixed with the gas,And with steam in the jacket heating,Heated to a temperature of 75 ° C;(4) the heated mixture into the reaction tube at a pressure sufficient reaction temperature,The pressure in the reaction tube is 2MPa,The temperature is 145 ,After the reaction of the gas entrained with the finished sodium formate by the cyclone separator, the gas emptying, the liquid gravity by gravity into the sodium formate tank |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
59% | bis-triphenylphosphine-palladium(II) chloride; In N,N-dimethyl-formamide; at 110℃; for 6h; | A mixture of 5-iodoindazole (10 g, 41 mmol) , HCOONa (5.57 g, 82 mmol) and PdCI2(PPh3J2 (1.44 g, 2.05 mmol) in DMF (60 mL) was put under vacuum and charged with carbon monoxide (CO). This process was repeated three times, after which the mixture was kept at 110 0C for 6 hr. After cooling to room temperature (rt), the reaction mixture was diluted with brine and extracted with EtOAc. The organic phases were combined, washed with brine, dried, and concentrated. The crude product was purified by column chromatography to afford 1 H-indazole-5-carboxaldehyde (3.52 g, 59%) as a white solid. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
54% | bis-triphenylphosphine-palladium(II) chloride; In N,N-dimethyl-formamide; at 110℃; for 6h; | A: A mixture of 5-bromo-1 H-indazole-3-carboxylic acid methyl ester (1 g, 3.92 mmol), HCOONa (400 mg, 5.88 mmol), and PdCI2(PPh3)2 (138 mg, 0.2 mmol) in DMF (10 mL) was put under vacuum, and charged with CO. This process was repeated three times, and the mixture was kept at 110 0C for 6 hr. The reaction mixture was cooled to rt, diluted with EtOAc and water, and extracted. The organic phase was dried and concentrated. Purification via flash chromatography afforded 5-formyl-1H-indazole-3-carboxylic acid methyl ester (430 mg, 54%). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Example 8; Obtaining (S)-N-ethyl-3-[1-(dimethylamino)ethyl]-N-methylphenylcarbamate [Rivastigmine] 2.5 mL of 98% formic acid, 0.4 g of sodium formiate and 1 mL of 37% formaldehyde aqueous solution are added to 0.5 g of the compound of formula (II) [Example 7]. The mixture is heated under reflux and maintained at this temperature until the end of the reaction. It is processed by adding 5 mL of methylene chloride and the mixture is adjusted to pH 8.7. The separated organic phase is distilled until obtaining a residue that is purified by column chromatography and is identified as the desired product. 1H NMR: delta 1.15-1.2 (2*t, 3H, N-CH2-CH3) ; delta 1.3 (d, 3H, -CH-CH3) ; delta 2.2 (s, 6H, N-CH3); delta 2.96-3.04 (2*s, 3H, OCN-CH3); 3.2 (q, 1H, -CH-CH3) ; delta 3.36-3. 44 (2*q, 2H, N-CH2-CH3) ; delta 6.96 (d, 1H, Ar-H); delta 7.05 (s, 1H, Ar-H); delta 7.10 (d, 1H, Ar-H); delta 7.3 (t, 1H, Ar-H) |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
37% | With carbon monoxide In N,N-dimethyl-formamide at 100℃; for 5h; | 92 To a solution of N-[4-([2-(dimethylamino)-7-iodoquinazolin-4- yl] amino }methyl)phenyl] -4-fluorobenzamide (417 mg, 0.75 mmol) in DMF 3 (mL) were added sodium formate (HCO2Na) (102 mg, 1.5 mmol) and PdCl2(PPh3)2 (26 mg, 5 mol%). The resulting mixture was heated at 100 0C under CO (gas, 1 atm) for 5h. Upon completion, the reaction mixture was cooled to RT, and poured into cold water. The resulting solid was collected by filtration, and purified by HPLC to give off- white solid (123 mg, 37%). MS(ESI) m/z 444.1. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
81% | at 190℃; for 4h; Neat (no solvent); Inert atmosphere; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Stage #1: sodium formate With acetyl chloride In diethyl ether at 20℃; Inert atmosphere; Stage #2: 2-pyrrolidinon In diethyl ether at 60℃; Inert atmosphere; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
87.4%; 5%; 99.7% | Example 1; The reaction solution with formaldehyde:acetaldehyde:alkaline=5.0:1:1.2 was prepared by dropping alkaline solution (32%) into the formaldehyde solution (12%) in 3 minutes after the pressure was stand at 0.2 Mpa by N2 and the initial temperature is at 45 t, then adding acetaldehyde solution (99%) in 80 minutes, and keeping the final temperature at 65 C. during the feeding by cycle cooling water. Thereafter, the solution was neutralized to pH=6 with formic acid, removed the redundant formaldehyde and methanol, crystallization solution was obtained by evaporation concentration, then pentaerythritol containing 91% monopentaerythritol was obtained with a single pass yield of 94.2%. Monopentaerythritol (98.3%) product was obtained by recrystallized the above pentaerythritol. The centrifuged mother liquor was filter, the filter residue was cascade dissolved-crystallized twice to obtain dipentaerythritol (93.3%). Rude sodium formate was obtained by concentrating crystallizing filtrate. The filtrate therefrom was diluted to time by water, then heated to dissolve, crystallized and centrifuged to overcome pentaerythritol. The mother liquor after overcoming pentaerythritol was return to overcome rude sodium formate again. The rude sodium formate was recrystallize to obtained sodium formate product with concentration of 96.5%. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
82% | With formic acid; In tetrahydrofuran; at 20℃; for 10.0h; | The compound 5 (1.24 g, 6.0 mmol), formic acid (2.23 g, 48.0 mmol) and sodium formate (82 mg, 1.2 mmol) were placed into a flask. The reaction was monitored with TLC and complete after 10 h of stirring at room temperature. The resulting mixture was poured onto 50 mL of water, and the suspension was stirred for 10 min. After stewing at 10 C for 10 min, the white precipitate was filtered to give the intermediate 6m. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
Ca. 20% | In water; N,N-dimethyl-formamide; at 140℃; for 48h;High pressure; Autoclave; | A mixture of Co(NO3)2·6H2O (0.1 mmol, 29 mg), HCOONa (0.2 mmol, 14 mg) and L (0.1 mmol, 29 mg) was suspended in 14 mL component solvent (H2O: DMF = 3: 4). The suspension was heated in a Teflon-lined autoclave (25 mL) at 140 C for 2 days. After the autoclave was cooled to room temperature at 10 C·h-1, pink block crystals suitable for single crystal X-ray crystallographic analysis were collected in ca. 20% yield (based on L). Anal. calcd for C40H32Co2N8O8: C, 55.18; H, 3.70; N, 12.87%. Found: C, 54.96; H, 3.77; N, 12.98%. IR (KBr, cm-1): 3444s, 3238s, 2840w, 2358w, 2077w, 1639s, 1617s, 1518m, 1413m, 1383m, 1355m, 1311m, 1247m, 1149m, 1127m, 1065m, 926w, 939w, 837m, 815w, 740w, 622s, and 480m. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
81.3% | Stage #1: sodium formate With acetic anhydride; N-ethyl-N,N-diisopropylamine at 20℃; for 1h; Inert atmosphere; Stage #2: ethyl 5-(((trifluoromethyl)sulfonyl)oxy)-3,6-dihydro-2H-pyran-4-carboxylate With palladium diacetate; lithium chloride In N,N-dimethyl-formamide at 20℃; for 1.5h; Inert atmosphere; | 7 Intermediate 8 4-(Ethoxycarbonyl)-5,6-dihvdro-2H-pyran-3-carboxylic acid Intermediate 8 4-(Ethoxycarbonyl)-5,6-dihvdro-2H-pyran-3-carboxylic acid A mixture of acetic anhydride (5.19 g, 4.8 mL, 50.9 mmol), DIPEA (6.58 g, 8.89 mL, 50.9 mmol) and sodium formate (5.19 g, 76.3 mmol) was stirred at RT for 1 h. A solution of ethyl 5- (trifluoromethylsulfonyloxy)-3,6-dihydro-2H-pyran-4-carboxylate (8.6 g, 25.4 mmol; prepared according to WO2010038167) in DMF (50 mL) was added dropwise, followed by the addition of palladium (II) acetate (286 mg, 1.27 mmol) and LiCl (3.24 g, 76.3 mmol). After stirring at RT for 1.5 h the black suspension was poured on 2M aqueous HC1 solution (100 mL) and EtOAc (100 mL) and the layers were separated. The aqueous layer was extracted twice with EtOAc (100 mL). The organic layers were washed twice with H20 and once with brine, dried over MgS04, filtered, treated with silica gel and evaporated. The compound was purified by silica gel chromatography on a 120 g column using an MPLC system eluting with a gradient of CH2C12 : MeOH (100 : 0 to 80 : 20). Light brown oil (4.14 g; 81.3%). MS (ESI): m/z = 199.06 [M-H]~. |
81.3% | Stage #1: sodium formate With acetic anhydride; N-ethyl-N,N-diisopropylamine In N,N-dimethyl-formamide at 20℃; for 1h; Stage #2: ethyl 5-(((trifluoromethyl)sulfonyl)oxy)-3,6-dihydro-2H-pyran-4-carboxylate With palladium diacetate; lithium chloride In N,N-dimethyl-formamide at 20℃; for 1.5h; | 4-(Ethoxycarbonyl)-5,6-dihydro-2H-pyran-3-carboxylic acid 4-(Ethoxycarbonyl)-5,6-dihydro-2H-pyran-3-carboxylic acid A mixture of acetic anhydride (5.19 g, 4.8 mL, 50.9 mmol), DIPEA (6.58 g, 8.89 mL, 50.9 mmol) and sodium formate (5.19 g, 76.3 mmol) was stirred at RT for 1 h. A solution of ethyl 5-(trifluoromethylsulfonyloxy)-3,6-dihydro-2H-pyran-4-carboxylate (8.6 g, 25.4 mmol; prepared according to WO2010038167) in DMF (50 mL) was added dropwise, followed by the addition of palladium (II) acetate (286 mg, 1.27 mmol) and LiCl (3.24 g, 76.3 mmol). After stirring at RT for 1.5 h the black suspension was poured on 2M aqueous HCl solution (100 mL) and EtOAc (100 mL) and the layers were separated. The aqueous layer was extracted twice with EtOAc (100 mL). The organic layers were washed twice with H2O and once with brine, dried over MgSO4, filtered, treated with silica gel and evaporated. The compound was purified by silica gel chromatography on a 120 g column using an MPLC system eluting with a gradient of CH2Cl2:MeOH (100:0 to 80:20). Light brown oil (4.14 g; 81.3%). MS (ESI): m/z=199.06 [M-H]-. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
98.98% | With sodium nitrite In water at 90℃; for 6h; | 3; 9 The effect of catalyst loading (Aeroxide P-90 Ti02 as catalyst) on reduction of calcium carbonate was studied using sodium nitrite as reducing agent. The Aeroxide P90 Ti02 catalyst loading was varied from 0.17 to 0.29 (w/v%) in order to find its effecton reduction of calcium carbonate. Initially known quantities of calcium carbonate (10 g/l), reducing agent sodium nitrite (12.9 g/l) was added into the water (350 ml). The reaction solution was stirred at 650 rpm and subsequently solution was heated at 90 C & atmospheric pressure for 6 hrs. When the desired reaction temperature (90 ‘C) was reached, then it was considered as the zero reaction time and sample was withdrawnthrough the sample tube as a zero time sample. Subsequently samples were withdrawn at specific time intervals through the sample tube. Table 9 shows the amount of sodium formate formed during the reduction reaction. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
64.79% | With sodium tetrahydroborate; copper(II) oxide In water at 90℃; for 6h; | 1 The reduction of ammonium carbonate was performed using sodium borohydride as reducing agent in the presence of various metal oxide catalyst such as Aeroxide P-90 Ti02 CuO, ZnO, and Cu as catalyst. Initially known quantities ofammonium carbonate (10 g/l), reducing agent sodium borohydride (10 g/l) and metal oxide catalyst (0.23 w/v%) were added into the water (350 ml). The reaction solution was stirred at 650 rpm and subsequently solution was heated at 90 C and atmospheric pressure for 6 hrs. When the desired reaction temperature (90 C) was reached, then it was considered as the zero reaction time and sample was withdrawn through thesample tube as a zero time sample. Subsequently samples were withdrawn at specific time intervals through the sample tube. Table 1 shows the amount of sodium formate formed during the reduction reaction. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
47% | With formic acid; acetic anhydride; at 50 - 60℃; for 4h; | 20 ml of acetic anhydride was added to a solution of 21.5 grams (0.12 mol) ofCompound 2 and 8.16 grams (0.12 mol) sodium formate in 200 ml of formic acid. Afier 2 hours, another 10 ml of acetic anhydride was added, and the mixture was stirred at a temperature of 50-60 C. for 2 hours. The solvent was then evaporated in vacuo. An aqueous solution of NaHCO3 was then added, and the obtained residue was extracted with ethyl acetate. The obtained organic phase was dried over Na2504 and evaporated in vacuum to give 9.0 grams of pure Compound 3, which solidified with time, at a yield of 47%. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
In water; at 100℃; | 200 g (0.68 mol) of <strong>[2304-30-5]tetra-n-butylphosphonium chloride</strong>,In an aqueous solution containing 80% of potassium formate was added 84 g (1.00 mol)Was added to the solution.In this state, since two phases were separated, water was added to make a homogeneous solution.This solution was concentrated under reduced pressure at 100 C.,Crystals of potassium chloride precipitated.The crystals were hot-filtered, and the filtrate containing the ionic liquid was recovered.The filtrate was dried under reduced pressure with an oil rotary pump to recover the regenerated ionic liquid.When this ionic liquid was analyzed by the Mohr method, the chloride ion concentration was 0.37 mol / kg.That is, it was found that 89% of the chloride ion in the model degraded ionic liquid was removed and replaced with formate ion. 14.3 g (0.048 mol) of <strong>[2304-30-5]tetra-n-butylphosphonium chloride</strong>,And 6.55 g (0.096 mol) of sodium formate,The same experiment as in Example 3-1 was carried out. As a result, it was found that 50% of the chloride ion in the model degraded ionic liquid was removed and replaced with formate ion. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
90.56% | With formic acid; for 12h;Reflux; | General procedure: A mixture of sodium formate (8.1 mmol), formic acid (12.5 mL)and various substituted N-phenylformamides (40.7 mmol) was stirred at reflux for 12 h. The progress of the reaction was monitored by TLC. After completion of the reaction, the reaction mixture was evaporated under reduced pressure. The solid was taken up inethyl acetate to form a solution which was successively washed with water (2 20 mL) and then evaporated under reduced pressure to obtain the corresponding amides 2a-e. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
89.07% | With formic acid for 12h; Reflux; | 5.1.2. General procedure for preparation of N-phenylformamides (2a-e) General procedure: A mixture of sodium formate (8.1 mmol), formic acid (12.5 mL)and various substituted N-phenylformamides (40.7 mmol) was stirred at reflux for 12 h. The progress of the reaction was monitored by TLC. After completion of the reaction, the reaction mixture was evaporated under reduced pressure. The solid was taken up inethyl acetate to form a solution which was successively washed with water (2 20 mL) and then evaporated under reduced pressure to obtain the corresponding amides 2a-e. |
81.5% | In formic acid at 20℃; for 12h; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
55.2% | With tetrasodium phenylporphyrintetrasulphonatoferrate(III); oxygen; sodium hydroxide In water at 150℃; for 3h; Autoclave; |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
1.0 g | With acetic anhydride; In tetrahydrofuran; at 45℃; for 1h; | A mixture of <strong>[39136-63-5]2-amino-5-phenylthiazole</strong> (CAS Number 39136-63-5; 1.0 g, 5.68 mmol) and sodium formate (0.39 g, 5.68 mmol) in THF (5 ml) was heated to 45C. Acetic anhydride (0.87 g, 8.52 mmol) was added and the reaction mixture was stirred at 45 C for 1 h. The resulting mixture was cooled to rt, poured into saturated NaHCC^ solution (100 ml) and extracted with EtOAc (3 x 50 ml). The combined organic phase was separated, dried over Na2S04, filtered and concentrated under reduced pressure yielding N-(5-phenylthiazol-2-yl)formamide (1.0 g, 4.90 mmol). This material was used for the next step without further purification. LCMS: Method C, 1.94 min, MS: ES- 203.28. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
94.1% | Stage #1: C29H35NO11 With hydrogen bromide In methanol at 15℃; for 0.333333h; Stage #2: With bromine In methanol for 2h; Stage #3: sodium formate Further stages; | 16 Example 16 Preparation of epirubicin hydrochloride hydrochloride: To 1000 mL of a three-necked glass reaction flask was added methanol,Intermediate VI (Intermediate VI: Methanol = 1: 40 (W / V, g / mL)). Open stirring, temperature control 15 ,A solution of 4% hydrogen bromide in methanol (Intermediate VI: 4% methanol solution of hydrogen bromide = 1: 4 (W / V, g / mL)) was added dropwise to the reaction solution,After completion of the dropwise addition, stirring for 20 minutes,A solution of bromine in the reaction solution (Intermediate VI: bromine: methanol = 1: 0.5: 5 (W / W / V, g / g / mL)After completion of the dropwise addition, the reaction was stirred for 2 hours.After the completion of the reaction, a sodium sulfite solution (Intermediate VI: sodium bisulfite: purified water = 1: 0.05: 0.5 (W / W / V, g / g / mL)) was added to the reaction solution, Ammonia adjusted pH of 4.5 to 5.0,After stirring for 10 minutes, the pH was adjusted to 1.3 to 1.5 with 7% hydrochloric acid solution, and the mixture was stirred at 25 ° C to 35 ° C for 2 hours. The reaction ends,Adding 25% sodium formate aqueous solution, adjusting the pH to 3.0 ~ 3.5, temperature control 25 ~ 35 sodium formate hydrolysis for 1 hour, the final target compound hydrochloric acid epirubicin crude solution. Dichloromethane and purified water were added to the reaction solution (Intermediate VI: purified water: dichloromethane = 1: 60: 30 (w / v / v, g / mL / mL)), , And the aqueous phase was extracted three times with methylene chloride solution (Intermediate VI: dichloromethane = 1: 30 (w / v, g / mL)),The organic phase was combined and concentrated to a volume in vacuo (Intermediate VI: volume of concentrate = 1: 10 (W / V, g / mL)), n-hexane (Intermediate VI: n-Hexane = 1: 10 (W / V, g / mL)), and dried by suction filtration to obtain solid epirubicin hydrochloride , the mass yield was 94.1%.The product is red powder, the purity of 98.7%, to meet the requirements of the Pharmacopoeia: test solution for the chromatogram if the impurity peak, doxorubicin (relative retention time of about 0.3) after the correction of the peak area(1.0%), doxorubicin (relative retention time of about 0.8) peak area shall not be greater than the control solution main peak area (1.0%), other single impurity peak area shall not be calculated (multiplied by the correction factor 0.7) (0.5%) of the main peak area of the control solution, and the area of each impurity peak area should not exceed 2 times (2.0%) of the main peak area of the control solution.Google Translate for Business:Translator ToolkitWebsite Translator |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
62% | With dimethyl amine; In water; at 120℃; for 72h;Autoclave; High pressure; | A mixture of Zn(NO3)2·6H2O (60 mg, 0.2 mmol), HCOONa·2H2O (14 mg, 0.1 mmol), Hdmtz(19 mg, 0.2 mmol), an aqueous dimethylamine solution (0.3 mmol, 33percent), and H2O (3 ml) was placed in a Teflon-linedstainless steel vessel (12 ml), heated at 120 °C for 72 h, and then cooled to room temperature at a rate of 5 °C/h. Colorlessblock crystals of 1 were collected by filtration, washed with water, and dried in air to afford 22 mg (62percent based on Zn) of theproduct. Anal. calcd. for C13H22N10O8Zn4 (percent): C 22.06, H 3.13, N 19.79. Found (percent): C 22.12, H 3.09, N, 19.82. IR(KBr, cm?1): 3476(m), 1612(s), 1527(m), 1451(m), 1385(m), 1340(m), 1129(w), 1036(w), 881(w), 772(w), 700(w), 546(m). |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
With triphenylphosphine; In N,N-dimethyl-formamide; at 110℃; under 6205.94 Torr; for 12.0h;Inert atmosphere; | To a solution of 6- bromoimidazo[1,2-ajpyridine (110 g, 558 mmol) in DMF (2.5 L) were added bis(triphenylphosphine)palladium(II) chloride (11.8 g, 16.8 mmol), sodium formate (98 g, 1.4 mol) and triphenylphosphine (7.3 g, 28 mmol). The reactionmixture was degassed and purged with CO. The reaction mixture was then stirred at 110 C under CO (120 psi) for 12 h, and concentrated down and the residue was purified by silica gel column chromatography (0-100% gradient EtOAc/hexanes) to give the product. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
86.9% | Stage #1: N<SUP>1</SUP>-hexadecyl-N<SUP>3</SUP>-(2-piperidylethyl)imidazolium chloride hydrochloride With sodium hydroxide In acetonitrile for 0.666667h; Stage #2: sodium formate In acetonitrile at 20℃; for 18h; | 1 Synthesis of N1-hexadecyl-N3-(2-piperidylethyl)imidazolecarboxylate: 4.77 g (10 mmol) of N1-hexadecyl-N3-(2-piperidinylethyl)imidazole hydrochloride was dissolved in 100 mL of acetonitrile.The reaction was carried out by adding 0.40 g (10 mmol) of sodium hydroxide under stirring for 40 minutes, and then 0.82 g (12 mmol) of sodium formate was added, and the reaction was stirred at room temperature for 12 hours.After the completion of the reaction, the insoluble matter was removed by filtration, and 0.14 g (2 mmol) of sodium formate was again added and reacted at room temperature for 6 hours.To exchange unreacted N1-hexadecyl-N3-(2-piperidinylethyl)imidazole.This operation was repeated 3-4 times until sodium formate was added and stirred without precipitation.Filtration, concentration of the filtrate, addition of diethyl ether to precipitate sodium formate, filtration, and the solvent was evaporated to remove the solvent.The milky white solid product, N1-hexadecyl-N3-(2-piperidinylethyl)imidazolecarboxylate, was 3.91 g, yield 86.9%. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
76% | Stage #1: sodium formate With N,N-diethyl-N-isopropylamine; acetic anhydride at 20℃; for 1h; Stage #2: C18H31F3O6SSi With palladium diacetate; lithium chloride In N,N-dimethyl-formamide at 20℃; | A mixture of HCO2Na (2.19 g, 32.2 mmol), Ac2O (2.03 mL, 21.5 mmol) and i-Pr2NEt (3.74mL, 21.5 mmol) was stirred for 1 h at room temperature. To the mixture were added 17 (4.95g, 10.7 mmol) in DMF (50 mL), Pd(OAc)2 (482 mg, 2.15 mmol) and LiCl (1.37 g, 32.3mmol), and stirring was continued overnight. The reaction mixture was filtered through a padof celite. The filtrate was poured into 1N HCl, and the mixture was extracted with Et2O. Theorganic layer was washed with water and brine, dried over MgSO4, and concentrated underreduced pressure. The residue was purified by silica gel column chromatography(hexane/EtOAc = 10:1 to 1:1) to afford 19 (2.92 g, 76%) as a colorless oil: IR (film) νmax 2944,1728, 1443, 1342, 1278, 1108, 1063, 1014, 882, 758, 682 cm-1; 1H NMR (400 MHz, CDCl3) δ4.01 (1H, dd, J = 9.6, 4.4 Hz), 3.90 (3H, s), 3.85 (1H, dd, J = 9.6, 3.6 Hz), 3.40 (1H, m),3.00-2.72 (2H, m), 2.12-1.94 (2H, m), 1.12-0.97 (21H, m); 13C NMR (100 MHz, CDCl3) δ168.69, 163.05, 147. 98, 140.22, 65.36, 53.48, 51.56, 34.78, 24.63, 17.88, 11.87; HRMS(ESI) calcd. for C18H32NaO5Si [M+Na]+ 379.1911, found 379.1906. |
Yield | Reaction Conditions | Operation in experiment |
---|---|---|
77% | In methanol; dimethyl sulfoxide; at 80℃;Inert atmosphere; | A dry and argon-flushed Schlenck-tube equipped with a magnetic stirrer and a septum was charged with a solution of 3 (1.0 g, 3.57 mmol) in dimethylsulfoxide (4 mL) and a solution of sodium methanoate in methanol (5.4 M, 1mL, 5.4 mmol) was added dropwise. The reaction mixture was stirred overnight at 80 C and was hydrolysed with water (20 mL). The mixture was extracted with EtOAc (3 x 30 mL), the organic phases were combined, washed with water (3 x 50 mL), brine (50 mL), dried over MgSO4, filtered and the solvent was evaporated under reduced pressure to afford the ester 5 (800 mg, 77%) as yellow oil. |
Tags: 141-53-7 synthesis path| 141-53-7 SDS| 141-53-7 COA| 141-53-7 purity| 141-53-7 application| 141-53-7 NMR| 141-53-7 COA| 141-53-7 structure
[ 54451-24-0 ]
Lanthanum(III) carbonate xhydrate
Similarity: 0.56
Precautionary Statements-General | |
Code | Phrase |
P101 | If medical advice is needed,have product container or label at hand. |
P102 | Keep out of reach of children. |
P103 | Read label before use |
Prevention | |
Code | Phrase |
P201 | Obtain special instructions before use. |
P202 | Do not handle until all safety precautions have been read and understood. |
P210 | Keep away from heat/sparks/open flames/hot surfaces. - No smoking. |
P211 | Do not spray on an open flame or other ignition source. |
P220 | Keep/Store away from clothing/combustible materials. |
P221 | Take any precaution to avoid mixing with combustibles |
P222 | Do not allow contact with air. |
P223 | Keep away from any possible contact with water, because of violent reaction and possible flash fire. |
P230 | Keep wetted |
P231 | Handle under inert gas. |
P232 | Protect from moisture. |
P233 | Keep container tightly closed. |
P234 | Keep only in original container. |
P235 | Keep cool |
P240 | Ground/bond container and receiving equipment. |
P241 | Use explosion-proof electrical/ventilating/lighting/equipment. |
P242 | Use only non-sparking tools. |
P243 | Take precautionary measures against static discharge. |
P244 | Keep reduction valves free from grease and oil. |
P250 | Do not subject to grinding/shock/friction. |
P251 | Pressurized container: Do not pierce or burn, even after use. |
P260 | Do not breathe dust/fume/gas/mist/vapours/spray. |
P261 | Avoid breathing dust/fume/gas/mist/vapours/spray. |
P262 | Do not get in eyes, on skin, or on clothing. |
P263 | Avoid contact during pregnancy/while nursing. |
P264 | Wash hands thoroughly after handling. |
P265 | Wash skin thouroughly after handling. |
P270 | Do not eat, drink or smoke when using this product. |
P271 | Use only outdoors or in a well-ventilated area. |
P272 | Contaminated work clothing should not be allowed out of the workplace. |
P273 | Avoid release to the environment. |
P280 | Wear protective gloves/protective clothing/eye protection/face protection. |
P281 | Use personal protective equipment as required. |
P282 | Wear cold insulating gloves/face shield/eye protection. |
P283 | Wear fire/flame resistant/retardant clothing. |
P284 | Wear respiratory protection. |
P285 | In case of inadequate ventilation wear respiratory protection. |
P231 + P232 | Handle under inert gas. Protect from moisture. |
P235 + P410 | Keep cool. Protect from sunlight. |
Response | |
Code | Phrase |
P301 | IF SWALLOWED: |
P304 | IF INHALED: |
P305 | IF IN EYES: |
P306 | IF ON CLOTHING: |
P307 | IF exposed: |
P308 | IF exposed or concerned: |
P309 | IF exposed or if you feel unwell: |
P310 | Immediately call a POISON CENTER or doctor/physician. |
P311 | Call a POISON CENTER or doctor/physician. |
P312 | Call a POISON CENTER or doctor/physician if you feel unwell. |
P313 | Get medical advice/attention. |
P314 | Get medical advice/attention if you feel unwell. |
P315 | Get immediate medical advice/attention. |
P320 | |
P302 + P352 | IF ON SKIN: wash with plenty of soap and water. |
P321 | |
P322 | |
P330 | Rinse mouth. |
P331 | Do NOT induce vomiting. |
P332 | IF SKIN irritation occurs: |
P333 | If skin irritation or rash occurs: |
P334 | Immerse in cool water/wrap n wet bandages. |
P335 | Brush off loose particles from skin. |
P336 | Thaw frosted parts with lukewarm water. Do not rub affected area. |
P337 | If eye irritation persists: |
P338 | Remove contact lenses, if present and easy to do. Continue rinsing. |
P340 | Remove victim to fresh air and keep at rest in a position comfortable for breathing. |
P341 | If breathing is difficult, remove victim to fresh air and keep at rest in a position comfortable for breathing. |
P342 | If experiencing respiratory symptoms: |
P350 | Gently wash with plenty of soap and water. |
P351 | Rinse cautiously with water for several minutes. |
P352 | Wash with plenty of soap and water. |
P353 | Rinse skin with water/shower. |
P360 | Rinse immediately contaminated clothing and skin with plenty of water before removing clothes. |
P361 | Remove/Take off immediately all contaminated clothing. |
P362 | Take off contaminated clothing and wash before reuse. |
P363 | Wash contaminated clothing before reuse. |
P370 | In case of fire: |
P371 | In case of major fire and large quantities: |
P372 | Explosion risk in case of fire. |
P373 | DO NOT fight fire when fire reaches explosives. |
P374 | Fight fire with normal precautions from a reasonable distance. |
P376 | Stop leak if safe to do so. Oxidising gases (section 2.4) 1 |
P377 | Leaking gas fire: Do not extinguish, unless leak can be stopped safely. |
P378 | |
P380 | Evacuate area. |
P381 | Eliminate all ignition sources if safe to do so. |
P390 | Absorb spillage to prevent material damage. |
P391 | Collect spillage. Hazardous to the aquatic environment |
P301 + P310 | IF SWALLOWED: Immediately call a POISON CENTER or doctor/physician. |
P301 + P312 | IF SWALLOWED: call a POISON CENTER or doctor/physician IF you feel unwell. |
P301 + P330 + P331 | IF SWALLOWED: Rinse mouth. Do NOT induce vomiting. |
P302 + P334 | IF ON SKIN: Immerse in cool water/wrap in wet bandages. |
P302 + P350 | IF ON SKIN: Gently wash with plenty of soap and water. |
P303 + P361 + P353 | IF ON SKIN (or hair): Remove/Take off Immediately all contaminated clothing. Rinse SKIN with water/shower. |
P304 + P312 | IF INHALED: Call a POISON CENTER or doctor/physician if you feel unwell. |
P304 + P340 | IF INHALED: Remove victim to fresh air and Keep at rest in a position comfortable for breathing. |
P304 + P341 | IF INHALED: If breathing is difficult, remove victim to fresh air and keep at rest in a position comfortable for breathing. |
P305 + P351 + P338 | IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. |
P306 + P360 | IF ON CLOTHING: Rinse Immediately contaminated CLOTHING and SKIN with plenty of water before removing clothes. |
P307 + P311 | IF exposed: call a POISON CENTER or doctor/physician. |
P308 + P313 | IF exposed or concerned: Get medical advice/attention. |
P309 + P311 | IF exposed or if you feel unwell: call a POISON CENTER or doctor/physician. |
P332 + P313 | IF SKIN irritation occurs: Get medical advice/attention. |
P333 + P313 | IF SKIN irritation or rash occurs: Get medical advice/attention. |
P335 + P334 | Brush off loose particles from skin. Immerse in cool water/wrap in wet bandages. |
P337 + P313 | IF eye irritation persists: Get medical advice/attention. |
P342 + P311 | IF experiencing respiratory symptoms: call a POISON CENTER or doctor/physician. |
P370 + P376 | In case of fire: Stop leak if safe to Do so. |
P370 + P378 | In case of fire: |
P370 + P380 | In case of fire: Evacuate area. |
P370 + P380 + P375 | In case of fire: Evacuate area. Fight fire remotely due to the risk of explosion. |
P371 + P380 + P375 | In case of major fire and large quantities: Evacuate area. Fight fire remotely due to the risk of explosion. |
Storage | |
Code | Phrase |
P401 | |
P402 | Store in a dry place. |
P403 | Store in a well-ventilated place. |
P404 | Store in a closed container. |
P405 | Store locked up. |
P406 | Store in corrosive resistant/ container with a resistant inner liner. |
P407 | Maintain air gap between stacks/pallets. |
P410 | Protect from sunlight. |
P411 | |
P412 | Do not expose to temperatures exceeding 50 oC/ 122 oF. |
P413 | |
P420 | Store away from other materials. |
P422 | |
P402 + P404 | Store in a dry place. Store in a closed container. |
P403 + P233 | Store in a well-ventilated place. Keep container tightly closed. |
P403 + P235 | Store in a well-ventilated place. Keep cool. |
P410 + P403 | Protect from sunlight. Store in a well-ventilated place. |
P410 + P412 | Protect from sunlight. Do not expose to temperatures exceeding 50 oC/122oF. |
P411 + P235 | Keep cool. |
Disposal | |
Code | Phrase |
P501 | Dispose of contents/container to ... |
P502 | Refer to manufacturer/supplier for information on recovery/recycling |
Physical hazards | |
Code | Phrase |
H200 | Unstable explosive |
H201 | Explosive; mass explosion hazard |
H202 | Explosive; severe projection hazard |
H203 | Explosive; fire, blast or projection hazard |
H204 | Fire or projection hazard |
H205 | May mass explode in fire |
H220 | Extremely flammable gas |
H221 | Flammable gas |
H222 | Extremely flammable aerosol |
H223 | Flammable aerosol |
H224 | Extremely flammable liquid and vapour |
H225 | Highly flammable liquid and vapour |
H226 | Flammable liquid and vapour |
H227 | Combustible liquid |
H228 | Flammable solid |
H229 | Pressurized container: may burst if heated |
H230 | May react explosively even in the absence of air |
H231 | May react explosively even in the absence of air at elevated pressure and/or temperature |
H240 | Heating may cause an explosion |
H241 | Heating may cause a fire or explosion |
H242 | Heating may cause a fire |
H250 | Catches fire spontaneously if exposed to air |
H251 | Self-heating; may catch fire |
H252 | Self-heating in large quantities; may catch fire |
H260 | In contact with water releases flammable gases which may ignite spontaneously |
H261 | In contact with water releases flammable gas |
H270 | May cause or intensify fire; oxidizer |
H271 | May cause fire or explosion; strong oxidizer |
H272 | May intensify fire; oxidizer |
H280 | Contains gas under pressure; may explode if heated |
H281 | Contains refrigerated gas; may cause cryogenic burns or injury |
H290 | May be corrosive to metals |
Health hazards | |
Code | Phrase |
H300 | Fatal if swallowed |
H301 | Toxic if swallowed |
H302 | Harmful if swallowed |
H303 | May be harmful if swallowed |
H304 | May be fatal if swallowed and enters airways |
H305 | May be harmful if swallowed and enters airways |
H310 | Fatal in contact with skin |
H311 | Toxic in contact with skin |
H312 | Harmful in contact with skin |
H313 | May be harmful in contact with skin |
H314 | Causes severe skin burns and eye damage |
H315 | Causes skin irritation |
H316 | Causes mild skin irritation |
H317 | May cause an allergic skin reaction |
H318 | Causes serious eye damage |
H319 | Causes serious eye irritation |
H320 | Causes eye irritation |
H330 | Fatal if inhaled |
H331 | Toxic if inhaled |
H332 | Harmful if inhaled |
H333 | May be harmful if inhaled |
H334 | May cause allergy or asthma symptoms or breathing difficulties if inhaled |
H335 | May cause respiratory irritation |
H336 | May cause drowsiness or dizziness |
H340 | May cause genetic defects |
H341 | Suspected of causing genetic defects |
H350 | May cause cancer |
H351 | Suspected of causing cancer |
H360 | May damage fertility or the unborn child |
H361 | Suspected of damaging fertility or the unborn child |
H361d | Suspected of damaging the unborn child |
H362 | May cause harm to breast-fed children |
H370 | Causes damage to organs |
H371 | May cause damage to organs |
H372 | Causes damage to organs through prolonged or repeated exposure |
H373 | May cause damage to organs through prolonged or repeated exposure |
Environmental hazards | |
Code | Phrase |
H400 | Very toxic to aquatic life |
H401 | Toxic to aquatic life |
H402 | Harmful to aquatic life |
H410 | Very toxic to aquatic life with long-lasting effects |
H411 | Toxic to aquatic life with long-lasting effects |
H412 | Harmful to aquatic life with long-lasting effects |
H413 | May cause long-lasting harmful effects to aquatic life |
H420 | Harms public health and the environment by destroying ozone in the upper atmosphere |
Sorry,this product has been discontinued.
Home
* Country/Region
* Quantity Required :
* Cat. No.:
* CAS No :
* Product Name :
* Additional Information :
